Chapter 2: Pre-installation Guide:
Unpacking & placing of GENIUS Compact optical sorter
2/14
Operators & Maintenance Manual GENIUS Compact Version UK 0.1 © BESTnv
Pulsarr Industrial Research BV, Marinus van Meelweg 20, 5657 EN, EINDHOVEN, THE NETHERLANDS
General tel. +31 (40) 292 2622 - Service tel. +31 (40) 292 2620 - Fax. +31 (40) 292 2633 - Email: service.pulsarr@bestnv.com
Installing the GENIUS Compact optical sorter
The Purchaser will provide and install all piping for water, compressed air
and wiring for electricity.
The electrical wiring and the compressed air piping have to be laid up to the connection ends on top of
the machine. The Purchaser should connect the necessary piping and tubing for water, pressurized air
and nitrogen to the GENIUS Compact optical sorter. The wiring for the electricity should be laid with
the cable ends reaching into the machine, but the fi nal connections shall be made by the installation
engineer from BESTnv. All piping, tubing and wiring should be installed without initiating electricity, water,
nitrogen or compressed air supply. If new pipes are used, make sure to fl ush the pipes for a considerable
number of minutes (+/- 15 min.) before connecting the tubes to the GENIUS Compact. The last end of
the pressurized air piping should consist of fl exible tubing, so as to allow some fl exibility when positioning
the machine.
Attention : - Do not fi x the sorter unit to the fl oor before the fi nal position has been
determined by BESTnv’s service engineer during commissioning.
The purchaser will also install all necessary operating panels (starters, circuit breakers, cables, etc...
) between the GENIUS Compact sorter and the local power grid, as and when mandatory under local
legislation. BESTnv’s service engineer will do a complete check-up on the GENIUS Compact sorter
installation and make all necessary adjustments to put it in perfect working order before setting it into
operation.
Attention: - Do not weld on or near the GENIUS Sorter.
- Do not fi x items on any of the GENIUS Compact units without fi rst consulting
BESTnv. This could seriously obstruct service & operation of the machine.
- Never fi x any of the sorter parts to the fl oor before the position and location
of all parts has been approved by BESTnv’s installation engineer.
- Make sure there is enough free space around the GENIUS Compact optical
sorter, so as to leave all parts accessible for service and repair by BESTnv
engineers.
- Do not initiate the electricity, water and/or compressed air supply before the
installation engineer has approved the installation.
- Make sure the optical sorter does not come into contact with any other
machinery, in order to avoid the transfer of vibrations to the sorter which
might seriously hinder the sorting process and in certain cases cause
damages to the sorter unit which are not covered under warranty.
