Chapter 7: Maintenance
Operators & Maintenance Manual GENIUS Compact Version UK 0.1 © BESTnv
BESTnv Industrial Research BV, Marinus van Meelweg 20, 5657 EN, EINDHOVEN, THE NETHERLANDS
General tel. +31 (40) 292 2622 - Service tel. +31 (40) 292 2620 - Fax. +31 (40) 292 2633 - Email: service.BESTnv@bestnv.com
7.7. Replacing the small return axle of the detection belt
(Only for GENIUS Compact 1200 mm version)
In optimal circumstances the return axle has a life span of +/- 2 years. But due to the fact that in practice
the detection belt is often strained too much, it is advisable too check it more often, and usually it has to
be replaced after +/- 1 year.
Before removing the old return axle, fi rst release the belt tension mechanism by screwing big hexagon
screw to the left.
Attention! - Be very careful not to damage the detection belt when removing and
replacing the return axle.
- After replacing the detection belt, always check tension and tracking (see
previous procedures).
