Best GENIUS Compact - IV. Operating the GENIUS Compact (continued); H. Water connections

4/7
Chapter 4: Operating the GENIUS Compact
Operators & Maintenance Manual GENIUS Compact Version UK 0.1 © BESTnv
BESTnv Industrial Research BV, Marinus van Meelweg 20, 5657 EN, EINDHOVEN, THE NETHERLANDS
General tel. +31 (40) 292 2622 - Service tel. +31 (40) 292 2620 - Fax. +31 (40) 292 2633 - Email: service.BESTnv@bestnv.com
Picture: Water supply cleaning system bottom unit (optional) underneath sorter unit
Picture: Belt cleaning system underneath belt, with water connections on both sides
B
B
C
C
A
A
B
B
A
A
H. Water connections
A: Water Connections to/from Cooling unit or mains water supply.
B: Water connection belt cleaning system
C: Water connection cleaning syst. bottom unit (option) underneath sorter (3/4” Gaz)
A: Water input cleaning system bottom unit (option)
B: Electronic water valve
