this drop-down menu to choose between the Stage (WYSIWYG) or Screen coordinate systems.
Stage (WYSIWYG): In the Stage coordinate system, the Z axis refers to the upward direction,
and Y is on the same plane as the X axis. (Used in WYSIWYG)
Screen: In the Screen coordinate system, the Z (and -Z) axis is on the same plane as the X
axis, and the Y axis refers to the upward direction.
Integer: Choose how integer data is sent. Click on this drop-down menu to change the network
order of integer fields output in RTTrPM packets from Big Endian (Network Order) to Little Endian
(Intel Order).
Float Point: Choose how the float variable value is defined. Click this drop-down menu and select
Big Endian (Network Order) or Little Endian (Intel Order).
Orientation: Click on this drop-down menu to change the Beacon orientation to Euler or Quaternion
coordinates.
Decimal Precision: Click this scroll box and set the decimal point precision for the X, Y, Z values
coming out of the RTTrPM.
Apply: Click to apply the settings.
Note: As a general rule, click Apply Changes to apply all changes that you set in Output Configuration.
