Brother MFC-9340CDW Service Manual

2-22
Confidential
AD00 First side scanned data cannot
be output with the required
number of pixels, and image
processing cannot be completed
successfully.
2-74
AF00 The first side CIS fails to move,
remaining at the home position.
2-74
B000 The first or second side CIS flat
cable was detected to be not
inserted correctly.
2-74
B300 ---
B400 ---
B700 During scanning, obtained
voltage was above the upper
limit.
2-75
B800 During scanning, obtained
voltage was below the lower
limit.
2-75
B900 During scanning, obtained white
level does not increase though
light intensity is increased.
2-75
BA00 ---
BB00 The white level value obtained
with function code 55 was
outside the specified range.
2-75
BC00 Though a fax was scanned again
after AC00 error, the second side
white or black calibration data
was not within the normal range.
2-75
BD00 The black level value obtained
with function code 55 was
outside the specified range.
2-75
BE00 ---
Error
codes
Problem
Refer
to:
BF00 The first side document scanning
position sensor detected that the
document was 400 mm or more
in length and could not be fed
from the ADF in duplex feeding.
2-76
C001 Timeout occurred with access
request sent to server due to
incorrect server address,
network disconnection, or
inactive server.
2-77
C002 User authentication is
unavailable due to incorrect user
name, incorrect password, or
asynchronous date and time
between the machine and server.
2-77
C003 Access to a file is unavailable
due to incorrect directory name,
no write permission on directory,
file write lock, or no write
permission on file.
2-77
C004 The current time necessary for
user authentication is
unavailable due to machine
clock (RTC) not being set and
time not being obtained through
SNTP.
2-77
C700 The memory is insufficient to
expand the data of PC-Print.
2-78
C800 The memory used to store
secure print data exceeded the
memory size for secure print
data.
2-78
C900 ---
CA00 ---
D100 An error occurred during modem
initialization.
2-78
D200 The machine detected that the
modem PCB was disconnected.
2-78
D800 An error occurred during touch
panel initialization.
2-79
Error
codes
Problem
Refer
to:

Brother MFC-9340CDW Specifications

Printing Specifications

print speed (black)	up to 23 ppm
print speed (color)	up to 23 ppm
print resolution	up to 600 x 2400 dpi
automatic duplex printing	Yes

Copying Specifications

copy speed (black)	up to 23 cpm
copy speed (color)	up to 23 cpm
copy resolution	600 x 600 dpi
copy reduction/enlargement	25% - 400% in 1% increments

Scanning Specifications

scanner type	Color Flatbed with ADF
document glass size	8.5” x 11.7”
scan resolution (optical)	1200 x 2400 dpi
scan resolution (interpolated)	19200 x 19200 dpi

Fax Specifications

fax modem	33.6k bps
fax page memory	up to 500 pages
speed dial locations	200

Memory and Interfaces

memory (standard/max)	192MB / 192MB
standard interfaces	Wireless 802.11b/g/n, Ethernet, Hi-Speed USB 2.0
usb direct interface	Yes

Supplies and Accessories

black toner cartridge yield	2, 500 pages
cyan toner cartridge yield (standard)	1, 400 pages
magenta toner cartridge yield (standard)	1, 400 pages
yellow toner cartridge yield (standard)	1, 400 pages
cyan toner cartridge yield (high capacity)	2, 200 pages
magenta toner cartridge yield (high capacity)	2, 200 pages
yellow toner cartridge yield (high capacity)	2, 200 pages
drum unit yield	15, 000 pages
belt unit yield	50, 000 pages
waste toner box yield	50, 000 pages
multi-purpose paper	Letter, 500 sheets
