Brother MFC-9340CDW Service Manual

2-23
Confidential
D900 An error occurred during panel
PCB initialization.
2-79
DA00 After the initialization of the panel
PCB, no response was sent from
the panel PCB for a period of
time.
2-79
DB00 Communication between the
main PCB and panel PCB is
unavailable.
2-80
E000 Some ROM checksum error
occurred.
2-80
E100 Program error. 2-80
E400 ---
E500 Error occurred when DRAM on
the main PCB ASSY was
accessed.
2-81
E600 Error occurred during writing to
EEPROM on the main PCB
ASSY.
2-81
E700 ---
EC00 Overcurrent was caused
because a USB device that did
not meet the specifications was
inserted into the USB port.
2-81
F900 Setting by country code is not
entered.
2-81
FA01 ---
FA02 ---
FA03 ---
FB01 ---
FB02 ---
FB03 ---
FB04 ---
FB05 ---
FB06 ---
Error
codes
Problem
Refer
to:
FB07 ---
FB08 ---
FB09 ---
FB0A ---
FB0B ---
FB0C ---
FB0D ---
FB0E ---
FB0F ---
FC01 ---
FC02 ---
FC03 ---
FC04 ---
FC05 ---
Error
codes
Problem
Refer
to:

Brother MFC-9340CDW Specifications

Printing Specifications

print speed (black)	up to 23 ppm
print speed (color)	up to 23 ppm
print resolution	up to 600 x 2400 dpi
automatic duplex printing	Yes

Copying Specifications

copy speed (black)	up to 23 cpm
copy speed (color)	up to 23 cpm
copy resolution	600 x 600 dpi
copy reduction/enlargement	25% - 400% in 1% increments

Scanning Specifications

scanner type	Color Flatbed with ADF
document glass size	8.5” x 11.7”
scan resolution (optical)	1200 x 2400 dpi
scan resolution (interpolated)	19200 x 19200 dpi

Fax Specifications

fax modem	33.6k bps
fax page memory	up to 500 pages
speed dial locations	200

Memory and Interfaces

memory (standard/max)	192MB / 192MB
standard interfaces	Wireless 802.11b/g/n, Ethernet, Hi-Speed USB 2.0
usb direct interface	Yes

Supplies and Accessories

black toner cartridge yield	2, 500 pages
cyan toner cartridge yield (standard)	1, 400 pages
magenta toner cartridge yield (standard)	1, 400 pages
yellow toner cartridge yield (standard)	1, 400 pages
cyan toner cartridge yield (high capacity)	2, 200 pages
magenta toner cartridge yield (high capacity)	2, 200 pages
yellow toner cartridge yield (high capacity)	2, 200 pages
drum unit yield	15, 000 pages
belt unit yield	50, 000 pages
waste toner box yield	50, 000 pages
multi-purpose paper	Letter, 500 sheets
