CALREC Putting Sound in the Picture 113
PC INfORMATION
Remote Access
USB connectors are provided on both the
front and rear of the PC for the option to
add an external modem of your choice.
If a modem is added, and a suitable
telephone line installed, the console can
be remotely accessed by Calrec Support
Engineers to aid software upgrades and
diagnostic work. This can greatly enhance
the level of service and support we can
provide. A dial-up facility must first be
activated at the PC before this is possible,
to ensure that connections are not made
at inappropriate times or without the
user’s knowledge and consent.
Local Network
A network port is provided to enable
the user to connect to their own LAN.
Calrec will not be responsible for the
configuration of this port or for any
performance issues arising from its use.
Hydra Network Connection
A Gigabit Ethernet port is provided to
enable the PC to be connected to a
Calrec Hydra Audio Network, which is an
option which can either be purchased with
the console or in the future.
Software Supplied
An OEM PC Operating System license
is supplied with each console, and the
operating system software is pre-installed.
The console software is also pre-installed,
and supplied on a CD-ROM.
3
rd
Party Software
Calrec recommends that the PC is
regarded as an integral control device for
the console, and not as a general purpose
PC. If 3
rd
party software is installed on the
PC, care must always be taken to ensure
Front
Rear
Windows XP
Intel Celeron Processor (2GHz+)
256 MB DDR RAM
40GB
52x
2 x 10/100
Compact Flash/Microdrive, SmartMedia,
Memory Stick, Secure Digital/Multimedia Card
4 (Rear of Unit), 1 (Front of Unit)
1 (Front of Unit)
8 Port Serial Card
that it does not interfere with the normal
performance of the PC. The installation
of inappropriate software on the PC may
invalidate the console warranty.
Usernames and Passwords
The PC will initially be set up with two sets
of usernames and passwords:
Username: CalrecAudio
Password: (none)
This user can install and run programs,
but cannot change PC hardware settings
(i.e. set up network, install drivers. It
is recommended that this user is used
during normal operation.
Username: CalrecAudioAdmin
Password: calrec
This user has full rights to the PC and can
install and change PC hardware settings.
It is recommended that this user is used
during configuration of the PC and the
setup of Hydra Audio Networking.
SD / MMC
MS
SM
CF / MD
USB
Power
Power
Reset
I O
DVD ROM
HDD
USB
USB
IEC
25F D-TYPE
9M D-TYPE 15F-SM D-TYPE
PARALLEL
TOUCH VGA
Calrec Console
Network
Customer
Network
USB 2
USB 2
Audio Line In
Mic In
Audio Line Out
Mouse
Keyboard
G
V
P
G
B
78F D-TYPE
SERIAL INTERFACE PORT
USB 2
USB 2
