Select the required fader by pressing
•
its Assign Button (A or B).
Select WILD ASSIGN 1, 2, 3 or 4.
•
Push one Assign panel rotary control. •
For example, Aux 1 Send.
Aux output controls cannot be assigned
to Wild controls. If the fader is touched
instead of pushing an Assign panel rotary
control, then the fader for the alternate
layer will be assigned to the Wild control.
If the track output level control is assigned
to a block of Wild controls, each fader’s
Wild control will have a different numbered
track output level control, beginning with
the track currently selected on the first
fader in the block.
I/PS
FLTR
EQ
DYN
ALL
FDR
AUXRTG
ALL
A
ALL
B
WILD ASSIGN
4
3
2
1
CLR
ALL
CHANNEL COPY
ALLDYN
FADER
BARGRAPH
I/P
OFF
HOLD
PAN
FUNCTIONS
CA4724
O/P
DIR
STEREO
EXT
TEST TONE
><
ENABLE
MONO
EXT
INTERRUPT
TONE
LEVEL
L
2=R
1=L
SWEEP
FREQUENCY
1k
< >
OSCILLATOR
A
<
B
>
EXEC
FADER
FADERSCONTROLS
DEFAULT
REPLAY
CLEAR
CONSOLE
CLEAR
SET UPCLEAR
AUX
CHANNEL GLOBAL
WILDS
ON
MIX MINUS BUS
DIRECT INPUT
COPY
FADER
TO
-11. dB
1012Hz + 1. dB
FDR19A
Drums
LEV
REF
CLEAR
TONE
SURR
EXT
WILD
ALT
EXEC
ONLY
0
0
wILD CONTROL ASSIgNMENT
The gains of the two inputs 1 and 2 can
be assigned separately to Wild controls,
by holding down the required input button
(1 or 2) on the Input/Output panel before
pushing the gain adjustment rotary
control.
CLR will clear the selected Wild control
from its assignment.
Multiple Wild Control Assignment
It is possible to assign controls to more
than one fader path at a time, either by
selecting individual fader assign buttons
(A or B), or by defining a “block” or
“Region” of faders.
After selecting Wild 1, 2, 3 or 4, press
HOLD, then a number of fader paths can
be selected individually by pressing their
fader assign buttons (A or B). Pushing an
Assign panel rotary control will assign that
control to all selected faders.
A block or region of faders can be defined
by holding down HOLD and then pressing
the fader assign buttons of the first and
last fader path in the required region.
Pushing an Assign panel rotary control will
assign that control to all fader paths in the
selected region.
It is possible to assign the same control
to Wilds 1, 2, 3 or 4 for all fader paths by
selecting ALL before pushing the required
Assign panel rotary control.
Alternate Wild Controls
The ALT WILD button allows switching
between two complete sets of Wild
settings. This would then allow up to 8
available Wild controls per fader.
