CALREC Putting Sound in the Picture 119
Unit Height
Width
Approx depth
(incl. mating cons)
Approx weight
Input Power
Rating
inches mm inches mm lbs kgs
AD5603
24 mic/line in & 8 line out - XLR
2U 19 483 12 300 12.5 5.7
100-240V AC ~
0.58-0.30A RMS
50/60Hz
AD5608
12 mic/line in & 4 line out - XLR
2U 19 483 12 300 11.5 5.2
100-240V AC ~
0.42-0.23A RMS
50/60Hz
AD5600
48 mic/line in & 16 line out - XLR
4U 19 483 12 300 16.1 7.3
100-240V AC ~
1.0-0.48A RMS
50/60Hz
JB5607
32 AES in & 32 AES out - BNC
3U 19 483 12 300 12 5.8
100-240V AC ~
0.38-0.20A RMS
50/60Hz
VI5672
4 SDI in and through
(rear connectors)
2U 19 483 12 300 13.9 6.3
100-240V AC ~
50/60Hz
As with the analog and AES-3 boxes,
these SDI interfaces connect to the
network via an Ethernet port on the rear
of the unit. Each unit has two identical
ports to provide network redundancy. All
versions are supplied with two RJ45 ports
for copper connections (1000BASE-T
for distances up to 90m = 290 feet).
Plug-in GBIC modules allow connections
with 1000BASE-SX (for distances up to
550m) and 1000BASE-LX (for distances
up to 10km) are available.
