Chery Automobile Co., Ltd.
23 - SUSPENSION
23–6
23
This model uses trailing arm type independent suspension for rear suspension, whose height is non-adjustable.
It is equipped with cylindrical coil spring, double action telescopic shock absorber and lateral stabilizer. This
suspension features easy-removal and quick-installation, and driving stability and ride comfort have greatly
improved.
Specifications
Torque Specifications
Description Torque (N·m)
Coupling Nut Between Front Stabilizer Link
Assembly and Front Shock Absorber Assembly
45 ± 5
Coupling Bolt Between Front Shock Absorber
Assembly and Front Steering Knuckle Assembly
180 ± 10
Coupling Nut Between Front Shock Absorber
Assembly and Front Steering Knuckle Assembly
180 ± 10
Coupling Nut Between Front Shock Absorber
Assembly and Body
60 ± 6
Front Shock Absorber Assembly Locking Nut 82 ± 5
Coupling Nut Between Front Control Arm Assembly
Ball Pin and Front Steering Knuckle Assembly
120 ± 12
Coupling Bolt Between Front Part of Front Control
Arm Assembly and Front Sub Frame Welding
Assembly
180 ± 10
Coupling Bolt Between Rear Part of Front Control
Arm Assembly and Front Sub Frame Welding
Assembly
180 ± 10
Coupling Nut Between Front Control Arm Ball Pin
Assembly and Front Control Arm Assembly
150 ± 10
Coupling Bolt Between Front Control Arm Ball Pin
Assembly and Front Control Arm Assembly
150 ± 10
Coupling Nut Between Front Stabilizer Bar Assembly
and Front Stabilizer Link Assembly
45 ± 5
Coupling Bolt Between Side Rail Welding Assembly
and Rear Mounting Cushion Assembly
70 ± 5
Coupling Nut Between Side Rail Welding Assembly
and Rear Mounting Cushion Assembly
70 ± 5
Coupling Bolt Between Front Sub Frame Welding
Assembly and Steering Gear Assembly
120 ± 10
Coupling Bolt Between Upper Part of Front Sub
Frame Welding Assembly and Body
180 ± 10
To Next Page
