Chery Automobile Co., Ltd.
04 - SERVICE SPECIFICATIONS
04–59
04
EXTERIOR
Specifications
Torque Specifications
Description Torque (N·m)
Front Name Plate CAC Assembly Fixing Screw 2.5 ± 0.5
Front Bumper Upper Grille Fixing Screw 2.5 ± 0.5
Front Bumper Assembly Fixing Screw 3 ± 1
Front Bumper Assembly Fixing Bolt 10 ± 1
Front Fog Assembly Fixing Screw 1.5 ± 0.5
Front Bumper Mounting Bracket Assembly Fixing
Bolt
10 ± 1
Headlight Fixing Bolt 3.5 ± 0.5
Front Bumper Upper Mounting Bracket Assembly
Fixing Bolt
10 ± 1
Front Bumper Lower Mounting Bracket Assembly
Fixing Bolt
10 ± 1
Front Bumper Crossmember Assembly Fixing Nut 23 ± 2
Apron Plate Cover Assembly Fixing Screw 3 ± 1
Apron Plate Assembly Fixing Screw 3 ± 1
Front Bumper Center Stiffener Bracket Assembly
Fixing Bolt
10 ± 1
Front Bumper Lower Stiffener Bracket Assembly
Fixing Nut
10 ± 1
Front Wheel House Protector Assembly Fixing
Screw
3 ± 1
Fender Assembly Fixing Bolt 10 ± 1
Engine Lower Protector Assembly Fixing Bolt 10 ± 1
Engine Lower Protector Assembly Fixing Screw 3 ± 1
Rear Bumper Assembly Fixing Screw 3 ± 1
Rear Bumper Assembly Fixing Bolt 3 ± 1
Rear Bumper Mounting Bracket Assembly Fixing
Screw
3 ± 1
Rear Bumper Crossmember Assembly Fixing Bolt 23 ± 2
Front Wheel House Protector Assembly of Rear
Wheel Fixing Screw
3 ± 1
Rear Wheel House Protector Assembly Fixing Screw 3 ± 1
Front Windshield Lower Garnish Assembly Fixing
Screw
3 ± 1
Roof Rack Assembly Fixing Bolt 9 ± 1
Rear Spoiler Assembly Fixing Nut 5 ± 1
