Chery Automobile Co., Ltd.
49 - INTERIOR
49–9
49
ON-VEHICLE SERVICE
Front Door Scuff Plate Assembly
Removal
HINT:
Use the same procedures for the right side and left side.
Procedures listed below are for the left side.
1. Remove the front left door scuff plate assembly.
a. Using an interior crow plate, pry up the claws of front
door scuff plate assembly, and remove the front left
door scuff plate assembly.
Installation
Installation is in the reverse order of removal.
Make sure to wear safety equipment to prevent accidents when removing the front door scuff plate
assembly.
Appropriate force should be applied when removing the front door scuff plate assembly. Be careful not to
operate roughly.
Prevent interior and body paint from being scratched when removing the front door scuff plate assembly.
Make sure front door scuff plate assembly is installed in place during installation.
