Chery Automobile Co., Ltd.
37 - DOOR LOCK
37–42
37
c. Detach the cable (arrow) connecting front door lock
assembly and front door assist grip base.
d. Remove 3 fixing screws (arrow) from front door lock
assembly, and remove the front door lock assembly.
ï€
(Tightening torque: 5.8 ± 0.7 N·m)
Inspection
1. Check front door lock assembly (fastener assembly).
a. Apply battery voltage to terminals of front door lock assembly (fastener assembly) connector and check
if front door lock assembly works properly according to the table below.
Front Left Door Lock Assembly
Measurement Condition
Specified
Condition
Battery positive (+) → Terminal 3
Battery negative (-) → Ter mi na l 2
Lock
Battery positive (+) → Terminal 2
Battery negative (-) → Ter mi na l 3
Unlock
To Next Page
