19 - CLUTCH
19–8
19
ON-VEHICLE SERVICE
Clutch Switch
Removal
1. Turn off all the electrical equipment and ignition switch.
2. Disconnect the negative battery cable.
3. Remove the clutch switch.
a. Disconnect the clutch switch connector (1) and
remove the clutch switch (2).
Inspection
Check for continuity between terminals when clutch switch is
turned on or off.
Installation
Installation is in the reverse order of removal.
1
2
RT21190060
12
-+
RT21190070
Switch Condition Specified Condition
ON (not pushed) Continuity
OFF (pushed) No continuity
