Chery T21 2014 - Turbine Speed Sensor; Removal; Installation

Chery Automobile Co., Ltd.
18 - QR019CHB CVT
18–116
18
Turbine Speed Sensor
Removal
1. Turn off all the electrical devices and ignition switch.
2. Disconnect the negative battery cable.
3. Remove the battery, battery tray and tray bracket (See page 16-7).
4. Remove the air filter (See page 10-17).
5. Disconnect the turbine speed sensor wire harness
connector (arrow).
6. Remove the fixing bolt (2) of the turbine speed sensor
and take out the turbine speed sensor (1).

(Tightening torque: 10 - 12 N·m)
Installation
Installation is in the reverse order of removal.
1
2
RT21180390
CAUTION
 Keep clean of sensor and contact surface between sensor and transmission, and avoid dust or impurity
entering the transmission.
 During installation, apply automatic transmission fluid on the O ring of the sensor.
