Chery Automobile Co., Ltd.
04 - SERVICE SPECIFICATIONS
04–41
04
AIR CONDITIONING
Specifications
Torque Specifications
Description Torque (N·m)
A/C Control Panel Assembly Fixing Screw 2.5 ± 0.5
Coupling Bolt Between A/C High/Low Pressure Line
and Expansion Valve
7 ± 1
Fixing Nut Between HVAC Assembly and Instrument
Panel Crossmember Assembly
7 ± 1
Fixing Bolt Between HVAC Assembly and Instrument
Panel Crossmember Assembly
4 ± 1
Fixing Bolt Between HVAC Assembly and Body 7 ± 1
Air Inlet Assembly Right Fixing Screw 2.5 ± 0.5
Air Inlet Assembly Left Fixing Screw 2.5 ± 0.5
Air Inlet Assembly Rear Fixing Screw 2.5 ± 0.5
Left Foot Fan Shield Fixing Screw 2.5 ± 0.5
Right Foot Fan Shield Fixing Screw 2.5 ± 0.5
Coupling Bolt Between Expansion Valve and
Expansion Valve Mounting Pressure Plate
7 ± 1
Blower Case Assembly Upper Fixing Screw 2.5 ± 0.5
Blower Case Assembly Lower Fixing Screw 2.5 ± 0.5
Evaporator Case Assembly Fixing Screw 2.5 ± 0.5
Heater Core Line Pressure Plate Fixing Screw 2.5 ± 0.5
Heater Core Line Cover Plate Fixing Screw 2.5 ± 0.5
Mode Damper Adjustment Mechanism Set Fixing
Screw
2.5 ± 0.5
Coupling Nut Between A/C High/Low Pressure Line
Fixing Bracket and Body
7 ± 1
Fixing Bolt Between A/C Low Pressure Line and
Compressor Assembly
25 ± 2.5
Fixing Bolt Between A/C High Pressure Line and
Compressor Assembly
25 ± 2.5
Fixing Nut Between A/C High Pressure Line I and
Condenser Assembly
7 ± 1
Fixing Nut Between A/C High Pressure Line II and
Condenser Assembly
7 ± 1
Coupling Bolt Between Rear Mounting Cushion
Assembly and Rear Mounting Bracket
70 ± 5
Coupling Nut Between Rear Mounting Cushion
Assembly and Rear Mounting Bracket
70 ± 5
To Next Page
