Chery T21 2014 - Hot Wire Air Flow Meter; Removal; Installation

Chery Automobile Co., Ltd.
10 - SQR484F INTAKE SYSTEM
10–13
10
Hot Wire Air Flow Meter
Removal
1. Turn off all the electrical equipment and ignition switch.
2. Disconnect the negative battery cable.
3. Remove the engine trim cover assembly (See page 10-10).
4. Remove the hot wire air flow meter.
a. Disconnect the hot wire air flow meter connector (1).
b. Remove 2 fixing bolts (arrow) from the hot wire air
flow meter.

(Tightening torque: 4.5 ± 0.5 N·m)
c. Remove the hot wire air flow meter.
Installation
Installation is in the reverse order of removal.
CAUTION
 Be sure to wear necessary safety equipment when repairing to prevent accidents.
 Try to prevent body paint surface from being scratched during removal and installation.
1
RT21100081
