Chery T21 2014 - Rear Right Door Wire Harness

Chery Automobile Co., Ltd.
51 - WIRE HARNESS
51–55
51
Rear Right Door Wire Harness
Connector Code Connector Color/Pin Connector Name
R-001 Gr/2 Rear Right Power Window Regulator Motor
R-002 W/16 to Body Wire Harness Connector B-005
R-003 B/10 Rear Right Power Window Switch
R-004 B/6 Rear Right Door Contact Switch
R-005 B/2 Rear Right Door Speaker
ET21510280
R-003
R-004
B-005
R-003R-002
R-001
R-005
