Chery T21 2014 User Manual

Chery Automobile Co., Ltd.
46 - SEAT
46–25
46
Rear Seat Assembly
Removal
HINT:
 Use the same procedures for the rear right seat assembly and rear left seat assembly.
 Procedures listed below are for the rear left seat assembly.
1. Remove the rear left seat headrest assembly.
a. As shown in the illustration, press the left seat
headrest guide w/ button and remove the rear left seat
headrest assembly.
2. Remove the rear left seat assembly.
a. Remove 2 fixing bolts (arrow) from the front part of
rear left seat assembly.

(Tightening torque: 50 ± 5 N·m)
b. Put down the rear left seatback in the direction of
arrow as shown in the illustration.
CAUTION
 Be sure to wear safety equipment to prevent accidents when removing rear seat assembly.
 Avoid scratch or damage to the body paint surface and carpet when removing rear seat assembly.
RT21460280
RT21460290
RT21460280
