Chery Automobile Co., Ltd.
15 - SQR484F STARTING SYSTEM
15–17
15
Diagnosis Procedure
HINT:
Perform troubleshooting according to the procedures below.
HINT:
In troubleshooting, confirm that the problem symptoms have been accurately identified. Preconceptions
should be discarded in order to make an accurate judgement. To clearly understand what the problem
symptoms are, it is extremely important to ask the customer about the problem and the conditions at the time
the malfunction occurred.
Standard voltage: 11 to 14 V
If voltage is below 11 V, recharge or replace the battery before proceeding to next step.
1
Vehicle brought to workshop
2
Customer problem analysis check
3
Check battery voltage
4
Read DTCs
go to step 5
go to step 7
5
Record DTCs, and clear DTCs
6
Verify and duplicate problem: simulate problem occurring condition, and read DTCs again
For current DTC, go to step 8
For history DTC, go to step 9
To Next Page
