Chery Automobile Co., Ltd.
45 - INSTRUMENT PANEL
45–23
45
b. Using a screwdriver wrapped with protective tape, pry
up the claws on instrument panel right outlet
assembly.
c. Remove the instrument panel right outlet assembly
from instrument panel assembly.
9. Remove the front passenger airbag.
a. Disengage the claws from front passenger airbag.
b. Remove the front passenger airbag from instrument
panel assembly.
Assembly
Assembly is in the reverse order of disassembly.
Installation
Installation is in the reverse order of removal.
Make sure to tighten fixing bolts and fixing screws to the specified torque when installing instrument
panel assembly.
Check airbag for proper installation after installing instrument panel assembly.
Check each electrical equipment for proper operation after installing instrument panel assembly.
