Chery Automobile Co., Ltd.
04 - SERVICE SPECIFICATIONS
04–61
04
INTERIOR
Specifications
Torque Specifications
Description Torque (N·m)
A-pillar Lower Protector Assembly Fixing Nut 5 ± 1
B-pillar Upper Protector Assembly Fixing Screw 1.5 ± 1
Back Door Baffle Plate Assembly Fixing Screw 1.5 ± 1
Back Door Baffle Plate Assembly Fixing Nut 1.5 ± 1
C-pillar Lower Protector Assembly Fixing Screw 1.5 ± 1
C-pillar Upper Protector Assembly Fixing Screw 1.5 ± 1
Sun Visor Assembly Fixing Screw 3 ± 0.5
Sun Visor Holder B Fixing Screw 3 ± 0.5
Front Seat Belt Assembly Lower Fixing Bolt 50 ± 5
Rear Seat Belt Lower Fixing Bolt 50 ± 5
Passenger Grip Assembly Fixing Bolt 5 ± 1
Interior Front Dome Light Assembly Fixing Screw 1.5 ± 0.5
Interior Rear Dome Light Assembly Fixing Screw 1.5 ± 0.5
High Pitched Speaker Fixing Screw 3 ± 0.5
Fuel Tank Opening Bracket Assembly Fixing Bolt 10 ± 1
Ground Wire Harness Fixing Nut 15 ± 2
