Chery Automobile Co.,
Ltd.
32 - SUPPLEMENTAL RESTRAINT SYSTEM
32–
63
32
g.
T
urn ignition
switch ON, and th
en select "Read Cod
e".
Replace SRS control module assembly
NG
OK
Malfunction has been solved and sys
tem operates normally
1502
1504
Table of Contents
FOREWORD
1
INTRODUCTION
7
SERVICE INFORMATION
9
How to Use This Manual
9
Preparation
10
Service Operation
13
VEHICLE INFORMATION
17
Vehicle Identification Information
17
Symbols
20
CIRCUIT DIAGNOSIS INFORMATION
21
How to Use Tester
21
ECM Control System Troubleshooting
21
Diagnosis and Troubleshooting
22
Circuit Simulation Test
23
Precautions for Control Module and Electrical Components Inspection
25
How to Check Connector
27
CIRCUIT INFORMATION
28
How to Read Circuit Diagram
28
Circuit Diagram Index
32
ABBREVIATION TABLE
34
Abbreviation Table
34
PREPARATION
37
SQR484F ENGINE MANAGEMENT SYSTEM
39
Tools
39
SQR484F ENGINE MECHANICAL
41
Tools
41
SQR484F FUEL SUPPLY SYSTEM
48
Tools
48
SQR484F EMISSION CONTROL SYSTEM
49
Tool
49
SQR484F INTAKE SYSTEM
50
Tools
50
SQR484F EXHAUST SYSTEM
51
Tools
51
SQR484F COOLING SYSTEM
52
Tools
52
SQR484F LUBRICATION SYSTEM
53
Tools
53
SQR484F IGNITION SYSTEM
54
Tool
54
SQR484F STARTING SYSTEM
55
Tools
55
SQR484F CHARGING SYSTEM
56
Tool
56
QR525MHE TRANSMISSION
57
Tools
57
QR019CHB CVT
59
Tools
59
CLUTCH
60
Tools
60
DIFFERENTIAL
61
Tools
61
AXLE
62
Tools
62
SUSPENSION
64
Tools
64
BRAKE CONTROL SYSTEM
65
Tools
65
BRAKE
66
Tools
66
PARKING BRAKE
67
Tools
67
STEERING COLUMN
68
Tools
68
HYDRAULIC ASSIST STEERING
69
Tool
69
ELECTRONIC POWER STEERING
70
Tools
70
AIR CONDITIONING
71
Tools
71
SUPPLEMENTAL RESTRAINT SYSTEM
72
Tools
72
SEAT BELT
73
Tool
73
ENGINE IMMOBILIZER
74
Tools
74
LIGHTING SYSTEM
75
Tools
75
WIPER AND WASHER
76
Tool
76
DOOR LOCK
77
Tools
77
INSTRUMENT CLUSTER
78
Tools
78
AUDIO SYSTEM
79
Tool
79
REVERSING RADAR SYSTEM
80
Tool
80
HORN
81
Tool
81
WINDSHIELD/WINDOW GLASS
82
Tools
82
REAR VIEW MIRROR
83
Tool
83
INSTRUMENT PANEL
84
Tools
84
SEAT
85
Tool
85
ENGINE HOOD/DOOR
86
Tool
86
EXTERIOR
87
Tool
87
INTERIOR
88
Tool
88
SERVICE SPECIFICATIONS
89
SQR484F ENGINE MANAGEMENT SYSTEM
91
Specifications
91
SQR484F ENGINE MECHANICAL
92
Specifications
92
SQR484F FUEL SUPPLY SYSTEM
100
Specifications
100
SQR484F EMISSION CONTROL SYSTEM
101
Specifications
101
SQR484F INTAKE SYSTEM
102
Specifications
102
SQR484F EXHAUST SYSTEM
103
Specifications
103
SQR484F COOLING SYSTEM
104
Specifications
104
SQR484F LUBRICATION SYSTEM
106
Specifications
106
SQR484F IGNITION SYSTEM
107
Specifications
107
SQR484F STARTING SYSTEM
108
Specifications
108
SQR484F CHARGING SYSTEM
109
Specifications
109
QR525MHE TRANSMISSION
110
Specifications
110
QR019CHB CVT
111
Specifications
111
CLUTCH
113
Specifications
113
DRIVE SHAFT
114
Specifications
114
DIFFERENTIAL
115
Specifications
115
AXLE
116
Specifications
116
SUSPENSION
118
Specifications
118
TIRE AND WHEEL
121
Specifications
121
BRAKE CONTROL SYSTEM
122
Specifications
122
BRAKE
123
Specifications
123
PARKING BRAKE
125
Specifications
125
STEERING COLUMN
126
Specifications
126
HYDRAULIC ASSIST STEERING
127
Specifications
127
ELECTRONIC POWER STEERING
128
Specifications
128
AIR CONDITIONING
129
Specifications
129
SUPPLEMENTAL RESTRAINT SYSTEM
131
Specifications
131
SEAT BELT
132
Specifications
132
LIGHTING SYSTEM
133
Specifications
133
WIPER AND WASHER
134
Specifications
134
DOOR LOCK
135
Specifications
135
NSTRUMENT CLUSTER
136
Specification
136
AUDIO SYSTEM
137
Specifications
137
REVERSING RADAR SYSTEM
138
Specification
138
HORN
139
Specification
139
WINDSHIELD/WINDOW GLASS
140
Specifications
140
REAR VIEW MIRROR
141
Specifications
141
INSTRUMENT PANEL
142
Specifications
142
SEAT
144
Specifications
144
ENGINE HOOD/DOOR
145
Specifications
145
EXTERIOR
147
Specifications
147
INTERIOR
149
Specifications
149
MAINTENANCE
151
MAINTENANCE ITEMS
153
Maintenance Schedule Table
153
REPLACEMENT INSTRUCTION
156
ADJUSTMENT ITEM
157
INSPECTION ITEMS
158
Off-vehicle Inspection
158
On-vehicle Inspection
158
Engine Compartment Inspection
160
Brake System Inspection
160
Power Steering System Inspection
161
Chassis Inspection
162
Final Inspection
163
SQR484F ENGINE MANAGEMENT SYSTEM
165
GENERAL INFORMATION
167
Description
167
System Function
168
Precautions
169
Specifications
170
Tools
170
ECM Pin Definition
172
Circuit Diagram
174
DIAGNOSIS & TESTING
182
Diagnostic Help
182
Intermittent DTC Troubleshooting
182
Ground Inspection
182
Throttle Self-learning
183
Diagnostic Trouble Code (DTC) Chart
183
ECM Power Supply Circuit & Ground Circuit Testing
187
P0030-00
195
P0031-00
195
P0032-00
195
P0053-00
195
P0036-00
202
P0037-00
202
P0038-00
202
P0054-00
202
P0101-00
209
P0102-00
209
P0103-00
209
P0112-00
216
P0113-00
216
P0116-00
221
P0117-00
221
P0118-00
221
P0121-00
227
P0122-00
227
P0123-00
227
P0130-00
233
P0131-00
233
P0132-00
233
P0133-00
233
P0134-00
233
P2195-00
233
P2196-00
233
P0136-00
239
P0137-00
239
P0138-00
239
P0140-00
239
P2270-00
239
P2271-00
239
P0201-00
245
P0271-00
250
P1106-00
255
P1110-00
255
P1111-00
255
P1568-00
255
P0606-00
255
P0300-00
262
P0301-00
262
P0302-00
262
P0303-00
262
P0304-00
262
P0322-00
270
P0327-00
275
P0328-00
275
P0341-00
280
P0346-00
280
P0420-00
286
P0444-00
289
P0458-00
289
P0459-00
289
P0480-00
296
P0481-00
296
P0691-00
296
P0560-00
302
P0562-00
302
P0563-00
302
P0627-00
309
P0628-00
309
P0629-00
309
P0645-00
314
P0646-00
314
P0647-00
314
P0688-00
319
P0604-00
324
P0605-00
324
P1619-00
326
P0531-00
328
U0101-87
333
U0129-87
336
U0140-87
339
U0155-87
342
U0164-87
346
U0167-87
350
P000A-00
353
P000B-00
353
P0010-00
356
P0013-00
356
P0012-00
362
P0015-00
362
P0016-00
364
P0018-00
364
Engine Problem Symptom Diagnosis
373
ON-VEHICLE SERVICE
406
Intake/Exhaust VVT Control Valve
406
Description
406
Operation
406
Removal
406
Installation
406
Coolant Temperature Sensor
407
Description
407
Operation
407
Removal
407
Installation
408
Knock Sensor
409
Description
409
Operation
409
Removal
409
Installation
410
Oxygen Sensor
411
Description
411
Operation
411
Upstream Oxygen Sensor
411
Downstream Oxygen Sensor
411
Removal & Installation - Upstream Oxygen Sensor
411
Removal & Installation - Downstream Oxygen Sensor
411
Camshaft Position Sensor
412
Description
412
Operation
412
Removal
412
Installation
412
Engine Speed Sensor
413
Description
413
Operation
413
Removal
413
Installation
413
Air Flow Meter
414
Description
414
Operation
414
Removal & Installation
414
Ignition Coil
415
Description
415
Operation
415
Removal & Installation
415
Electric Fuel Pump
416
Description
416
Operation
416
Removal & Installation
416
Fuel Injector
417
Description
417
Operation
417
Removal & Installation
417
Electronic Throttle Assembly
418
Description
418
Operation
418
Removal & Installation
418
Canister Solenoid Valve
419
Description
419
Operation
419
Removal & Installation
419
Engine Control Module (ECM)
420
Description
420
Operation
420
Removal
420
Installation
421
SQR484F ENGINE MECHANICAL
423
GENERAL INFORMATION
425
Description
425
Operation
425
Specifications
425
Tools
434
DIAGNOSIS & TESTING
441
Engine Performance Diagnosis
441
Inspection
442
ON-VEHICLE SERVICE
445
Accessory Drive Belt
445
Description
445
Removal
446
Inspection
446
Installation
447
Adjustment
447
Idler Pulley Assembly
448
Removal
448
Inspection
448
Installation
448
Belt Tensioner Assembly
449
Removal
449
Inspection
449
Installation
449
Engine Timing Belt
450
Description
450
Removal
451
Inspection
453
Installation
454
Camshaft Oil Seal
458
Removal
458
Installation
460
Crankshaft Front Oil Seal
461
Removal
461
Installation
462
Flywheel
464
Removal
464
Inspection
464
Installation
465
Crankshaft Rear Oil Seal
466
Removal
466
Installation
467
Cylinder Head Cover
468
Removal
468
Installation
469
Camshaft
471
Description
471
Removal
472
Inspection
475
Installation
476
Cylinder Head
477
Description
477
Removal
478
Disassembly
479
Inspection
480
Assembly
483
Installation
485
Engine Mounting Assembly
486
Removal & Installation - Rear Mounting Assembly
486
Removal & Installation - Front Mounting Assembly
488
Removal & Installation - Left Mounting Assembly
489
Removal & Installation - Right Mounting Assembly
490
ENGINE UNIT REPAIR
492
Engine Assembly
492
Removal
492
Installation
499
Engine Block
500
Description
500
Disassembly
502
Inspection
508
Selection of Bearing Shell
515
Selection of Connecting Rod Bearing Shell
516
Assembly
516
SQR484F FUEL SUPPLY SYSTEM
521
GENERAL INFORMATION
523
Description
523
Specifications
524
Tools
525
Fuel Supply System Line Connection Diagram
526
Circuit Diagram
527
DIAGNOSIS & TESTING
529
Problem Symptoms Table
529
Fuel System Pressure Release
530
Fuel Supply System Pressure Test
531
ON-VEHICLE SERVICE
532
Fuel Filter Assembly
532
Removal
532
Installation
533
Electric Fuel Pump Assembly
534
On-vehicle Inspection
534
Removal
535
Installation
537
Filler Tube Assembly
538
Removal
538
Installation
540
Fuel Tank
541
Removal
541
Installation
545
Fuel Rail Injector Assembly
546
Removal
546
Inspection
547
Installation
547
SQR484F EMISSION CONTROL SYSTEM
549
GENERAL INFORMATION
551
Description
551
Specifications
552
Tool
552
Circuit Diagram
553
DIAGNOSIS & TESTING
554
Leakage Inspection
554
Activated Charcoal Canister Inspection
554
Fuel Tank Cap Assembly Inspection
554
ON-VEHICLE SERVICE
555
Activated Charcoal Canister Solenoid Valve and Bracket
555
Removal
555
Inspection
556
Installation
556
Activated Charcoal Canister Assembly
557
Removal
557
Installation
558
PCV Valve
559
Removal
559
Inspection
559
Installation
560
Upstream Oxygen Sensor
561
Removal
561
Inspection
562
Installation
562
Downstream Oxygen Sensor
563
Removal
563
Inspection
563
Installation
563
SQR484F INTAKE SYSTEM
565
GENERAL INFORMATION
567
Description
567
Specifications
568
Tools
568
Circuit Diagram
570
DIAGNOSIS & TESTING
573
Problem Symptoms Table
573
ON-VEHICLE SERVICE
574
Engine Trim Cover Assembly & Bracket
574
Removal
574
Installation
576
Hot Wire Air Flow Meter
577
Removal
577
Installation
577
Air Filter Element
578
Removal
578
Installation
579
Air Induction Pipe Assembly
580
Removal
580
Installation
580
Air Filter Assembly & Bracket
581
Removal
581
Installation
583
Electronic Throttle Assembly
584
On-vehicle Inspection
584
Removal
584
Inspection
586
Cleaning
586
Installation
587
Intake Manifold Assembly
588
Removal
588
Inspection
590
Installation
590
Electronic Accelerator Pedal
591
Removal
591
Installation
591
SQR484F EXHAUST SYSTEM
593
GENERAL INFORMATION
595
Description
595
Specifications
596
Tools
597
DIAGNOSIS & TESTING
598
Problem Symptoms Table
598
Exhaust System Gas Leakage Inspection
598
ON-VEHICLE SERVICE
599
Exhaust Manifold Assembly
599
Removal
599
Inspection
600
Installation
601
Precatalytic Converter Assembly
602
Removal
602
Installation
604
Main Catalytic Converter Assembly
605
Removal
605
Installation
606
Center Pipe Assembly
607
Removal
607
Installation
608
Muffler Assembly
609
Removal
609
Installation
611
SQR484F COOLING SYSTEM
613
GENERAL INFORMATION
615
Description
615
Specifications
617
Tools
618
Cooling System Operation Flowchart
619
Circuit Diagram
621
DIAGNOSIS & TESTING
622
Problem Symptoms Table
622
Cooling System Leakage Test
623
Coolant Concentration Test
624
ON-VEHICLE SERVICE
625
Coolant Replacement
625
Coolant Draining
625
Coolant Adding
626
Tank Upper Crossmember Assembly
628
Removal
628
Installation
629
Expansion Tank
630
Removal
630
Installation
630
Thermostat
631
Removal
631
Inspection
632
Installation
633
Thermostat Seat
634
Removal
634
Installation
636
Fan Controller
637
Removal
637
Installation
637
Cooling Fan Assembly
638
On-vehicle Inspection
638
Removal
638
Installation
640
Radiator Assembly
641
Removal
641
Installation
642
Water Pump Assembly
643
Removal
643
Inspection
644
Installation
644
SQR484F LUBRICATION SYSTEM
645
GENERAL INFORMATION
647
Description
647
Specifications
649
Tools
650
Lubrication System Flowchart
651
DIAGNOSIS & TESTING
652
Problem Symptoms Table
652
Engine Oil Level Inspection
653
Oil Pressure Inspection
654
ON-VEHICLE SERVICE
655
Engine Oil Replacement
655
Engine Oil Draining
655
Engine Oil Adding
656
Oil Filter
657
Removal
657
Installation
658
Oil Dipstick Tube
659
Removal
659
Installation
659
Oil Pressure Switch
660
Removal
660
Inspection
660
Installation
661
Oil Cooler Assembly
662
Removal
662
Installation
663
Oil Pan
664
Removal
664
Installation
666
Oil Strainer
667
Removal
667
Installation
667
Oil Pump Assembly
668
Removal
668
Installation
669
SQR484F IGNITION SYSTEM
671
GENERAL INFORMATION
673
Description
673
Operation
674
Specifications
674
Tool
674
Circuit Diagram
675
DIAGNOSIS & TESTING
676
Problem Symptoms Table
676
Service Precautions
677
ON-VEHICLE SERVICE
678
High-voltage Cable
678
Removal
678
Inspection
679
Installation
679
Ignition Coil
680
Removal
680
Inspection
681
Installation
681
Spark Plug
682
Removal
682
Inspection
683
Installation
683
SQR484F STARTING SYSTEM
685
GENERAL INFORMATION
687
Description
687
Operation
690
Specifications
691
Tools
691
Circuit Diagram
692
DIAGNOSIS & TESTING
698
Problem Symptoms Table
698
Starter Relay Inspection
699
Precautions for Starting System
700
Diagnosis Procedure
701
Problem Repair (No DTC)
703
Diagnostic Help
703
Intermittent DTC Troubleshooting
703
Ground Inspection
704
Passive Entry & Passive Start (PEPS) Controller Terminal List
704
Diagnostic Trouble Code (DTC) Chart
706
B1500-13
707
B1501-13
707
B1516-19
707
B1517-23
707
B1502-13
714
B1503-13
714
B1504-13
714
B1506-00
721
B1507-00
725
B1508-00
725
B1509-00
732
B1510-00
736
B1514-00
740
ON-VEHICLE SERVICE
748
Starter
748
Removal
748
Inspection
748
Installation
750
Ignition Starting Switch (w/o PEPS System)
751
Removal
751
Inspection
752
Installation
752
Engine Switch (w/ PEPS System)
753
Removal
753
Inspection
754
Installation
754
Passive Entry & Passive Start (PEPS) Controller (w/ PEPS System)
755
Removal
755
Installation
755
SQR484F CHARGING SYSTEM
757
GENERAL INFORMATION
759
Description
759
Alternator Operation
760
Specifications
760
Tool
760
Circuit Diagram
761
DIAGNOSIS & TESTING
762
Problem Symptoms Table
762
Charging System Charging Voltage Inspection
762
ON-VEHICLE SERVICE
763
Battery
763
Inspection
763
Removal
763
Installation
764
Battery Tray and Tray Bracket
765
Removal
765
Installation
765
Alternator
766
Removal
766
Installation
767
QR525MHE TRANSMISSION
769
GENERAL INFORMATION
771
Description
771
Operation
776
Specifications
776
Daily Maintenance
777
Tools
777
DIAGNOSIS & TESTING
780
Problem Symptoms Table
780
On-vehicle Inspection
781
ON-VEHICLE SERVICE
782
Transmission Oil
782
Replacement
782
Differential Oil Seal
784
Removal
784
Installation
784
Select and Shift Cable
786
Removal
786
Installation
787
Gear Shift Control Mechanism
788
Removal
788
Installation
788
Transmission Assembly
789
Removal
789
Disassembly
790
Assembly
795
Installation
800
Gear Shift Mechanism
801
Disassembly
801
Assembly
802
Shift Fork
803
Disassembly
803
Inspection
805
Assembly
805
Input Shaft
806
Disassembly
806
Assembly
810
Inspection
815
Output Shaft
816
Disassembly
816
Assembly
820
Inspection
824
Transmission External Accessory
825
Removal
825
Installation
826
Transmission Case
828
Disassembly
828
Assembly
831
QR019CHB CVT
835
GENERAL INFORMATION
837
Description
837
Precautions
841
Operation
841
Tools
847
Specifications
848
Circuit Diagram
849
Transmission Control Unit (TCU) Pin-Out Table
854
DIAGNOSIS & TESTING
855
Transmission Fluid Level and Quality Inspection
855
Gear Shift Cable Inspection and Adjustment
855
Transmission Range Sensor Inspection
856
Transmission Fluid Temperature Sensor Inspection
857
Primary Shaft Speed Sensor Inspection
857
Turbine/Secondary Shaft Speed Sensor Inspection
858
Problem Symptoms Table
860
Diagnostic Help
860
Intermittent DTC Troubleshooting
861
Ground Inspection
861
Diagnostic Trouble Code (DTC) Chart
861
Data Stream List
865
Power Supply and Ground Circuit Test
869
Power Supply Circuit Test
869
Ground Circuit Test
875
P0705
878
P0715
882
P0716
882
P0720
886
P1745
886
P0730
890
P0791
892
P0792
892
P0811
896
P081E
896
P0894
896
P0842
898
P0843
898
P0847
902
P0848
902
P0890
906
P0891
906
P0900
911
P0902
911
P0903
911
P0928
916
P0930
916
P0931
916
P0938
923
P0939
923
P0940
923
P0960
927
P0962
927
P0963
927
P0964
932
P0966
932
P0967
932
P0970
937
P0971
937
P2797
942
P2798
942
ON-VEHICLE SERVICE
944
Automatic Transmission Fluid (ATF) Replacement
944
Draining
944
Filling
944
Inspection
945
Differential Oil Seal
946
Removal
946
Installation
946
Transmission Fluid Cooler
947
Removal
947
Installation
947
Primary Shaft Speed Sensor
948
Removal
948
Installation
948
Secondary Shaft Speed Sensor
949
Removal
949
Installation
949
Turbine Speed Sensor
950
Removal
950
Installation
950
Primary Shaft Pressure Sensor
951
Removal
951
Installation
951
Secondary Shaft Pressure Sensor
952
Removal
952
Installation
952
Transmission Range Sensor
953
Removal
953
Installation
954
Valve Body Case
955
Removal
955
Installation
955
Valve Body
956
Removal
956
Installation
957
Gear Shift Control Mechanism
959
Removal
959
Installation
960
Gear Shift Cable
961
Removal
961
Installation
962
TCU
963
Removal
963
Installation
963
CVT Assembly
964
Removal
964
Installation
967
CLUTCH
969
GENERAL INFORMATION
971
Description
971
Operation
973
Specifications
973
Tools
974
DIAGNOSIS & TESTING
975
Problem Symptoms Table
975
ON-VEHICLE SERVICE
976
Clutch Switch
976
Removal
976
Inspection
976
Installation
976
Clutch Pedal
977
Removal
977
Installation
977
Clutch Master Cylinder Assembly
978
Removal
978
Installation
979
Clutch Release Cylinder Assembly
980
Removal
980
Installation
981
Clutch Unit
982
Removal
982
Inspection
982
Installation
983
Bleeding Hydraulic Clutch
984
DRIVE SHAFT
987
GENERAL INFORMATION
989
Description
989
Operation
990
Specifications
990
ON-VEHICLE SERVICE
991
Drive Shaft Assembly
991
Removal
991
Installation
993
Inner Ball Cage
994
Disassembly
994
Inspection
995
Assembly
996
Outer Ball Cage
997
Disassembly
997
Inspection
998
Assembly
998
DIFFERENTIAL
999
GENERAL INFORMATION
1001
Description
1001
Operation
1002
Specifications
1002
Tools
1003
DIAGNOSIS & TESTING
1004
Differential Gear Clearance Inspection
1004
ON-VEHICLE SERVICE
1005
Driven Gear of Final Drive
1005
Removal
1005
Installation
1005
Differential Bearing
1006
Removal
1006
Installation
1006
Differential Planetary Gear
1007
Removal
1007
Installation
1007
Differential Parts Inspection
1007
AXLE
1009
GENERAL INFORMATION
1011
Description
1011
Specifications
1013
Tools
1014
DIAGNOSIS & TESTING
1016
Problem Symptoms Table
1016
ON-VEHICLE SERVICE
1017
Front Hub Assembly
1017
Removal
1017
Installation
1019
Front Steering Knuckle
1020
Removal
1020
Installation
1021
Side Rail Welding Assembly
1022
Removal
1022
Installation
1024
Front Sub Frame Welding Assembly
1025
Removal
1025
Installation
1026
Rear Hub Bearing Unit
1027
Removal
1027
Installation
1027
Rear Sub Frame Assembly
1028
Removal
1028
Installation
1029
SUSPENSION
1031
GENERAL INFORMATION
1033
Description
1033
Specifications
1036
Tools
1039
DIAGNOSIS & TESTING
1040
Problem Symptoms Table
1040
ON-VEHICLE SERVICE
1042
Front Shock Absorber Assembly
1042
On-vehicle Inspection
1043
Removal
1043
Disassembly
1045
Inspection
1048
Assembly
1048
Installation
1048
Disposal
1049
Front Control Arm Assembly
1050
Removal
1050
Installation
1051
Front Control Arm Ball Pin Assembly
1052
Removal
1052
Inspection
1053
Installation
1053
Front Stabilizer Bar Assembly
1054
Removal
1054
Inspection
1056
Installation
1056
Front Stabilizer Link Assembly
1057
Removal
1057
Inspection
1057
Installation
1058
Rear Shock Absorber Assembly
1059
Removal
1060
Inspection
1062
Installation
1062
Disposal
1063
Rear Coil Spring
1064
Removal
1064
Inspection
1066
Installation
1066
Rear Suspension Upper Swing Arm Assembly
1067
Removal
1067
Installation
1067
Rear Suspension Lower Swing Arm Assembly
1068
Removal
1068
Installation
1069
Rear Trailing Arm Assembly
1070
Removal
1070
Installation
1072
Rear Stabilizer Bar Assembly
1073
Removal
1073
Inspection
1074
Installation
1074
Rear Stabilizer Link Assembly
1075
Removal
1075
Inspection
1075
Installation
1076
WHEEL ALIGNMENT
1077
Description
1077
Specifications
1077
Problem Symptoms Table
1078
Inspection before Wheel Alignment
1078
Front Wheel Toe-in
1079
Inspection
1079
Adjustment
1080
Front Wheel Camber, Kingpin Caster & Kingpin Inclination
1081
Rear Wheel Camber
1082
Adjustment
1082
Rear Wheel Toe-in
1083
Adjustment
1083
TIRE AND WHEEL
1085
GENERAL INFORMATION
1087
Precautions
1087
Tire Identification
1087
Specifications
1088
DIAGNOSIS & TESTING
1089
Problem Symptoms Table
1089
Inspection
1089
ON-VEHICLE SERVICE
1091
Tire Replacement
1091
Wheel
1093
Removal
1093
Installation
1093
Wheel Balance
1094
Adjustment
1094
Tire Rotation
1095
Description
1095
Rotation Method
1095
BRAKE CONTROL SYSTEM
1097
GENERAL INFORMATION
1099
Description
1099
Operation
1100
Specifications
1105
Tools
1106
Circuit Diagram
1107
DIAGNOSIS & TESTING
1110
Problem Symptoms Table
1110
Diagnosis Procedure
1110
Problem Repair (No DTC)
1112
DTC Confirmation Procedure
1112
Intermittent DTC Troubleshooting
1113
Ground Inspection
1113
ABS Control Module Assembly Terminal List
1114
Diagnostic Trouble Code (DTC) Chart
1115
C0010-04
1117
C0011-04
1117
C0014-04
1117
C0015-04
1117
C0018-04
1117
C0019-04
1117
C001C-04
1117
C001D-04
1117
C1003-04
1117
C1004-00
1117
C0020-04
1122
C0031-00
1126
C0031-09
1126
C0031-11
1126
C0031-12
1126
C0031-13
1126
C0031-29
1126
C0034-00
1132
C0034-09
1132
C0034-11
1132
C0034-12
1132
C0034-13
1132
C0034-29
1132
C0037-00
1138
C0037-09
1138
C0037-11
1138
C0037-12
1138
C0037-13
1138
C0037-29
1138
C003A-00
1145
C003A-09
1145
C003A-11
1145
C003A-12
1145
C003A-13
1145
C003A-29
1145
C006B-00
1152
C1000-16
1158
C1000-17
1158
C1001-04
1162
C1009-00
1162
ON-VEHICLE SERVICE
1166
ABS Bleeding
1166
ABS Control Module Assembly
1167
Removal
1167
Disassembly
1168
Assembly
1169
Installation
1169
Front Wheel Speed Sensor
1170
Removal
1170
Inspection
1171
Installation
1171
Rear Wheel Speed Sensor
1172
Removal
1172
Inspection
1173
Installation
1173
BRAKE
1175
GENERAL INFORMATION
1177
Description
1177
Specifications
1179
Tools
1181
Circuit Diagram
1182
DIAGNOSIS & TESTING
1183
Problem Symptoms Table
1183
Inspection
1185
ON-VEHICLE SERVICE
1186
Brake Bleeding
1186
Brake Fluid Replacement
1187
Brake Fluid Reservoir Assembly
1188
On-vehicle Inspection
1188
Removal
1188
Installation
1189
Brake Master Cylinder Assembly
1190
Removal
1190
Installation
1192
Vacuum Booster with Brake Master Cylinder Assembly
1193
On-vehicle Inspection
1193
Removal
1194
Inspection
1196
Installation
1196
Brake Pedal Assembly
1197
On-vehicle Inspection
1197
Removal
1198
Inspection
1200
Installation
1200
Front Disc Brake Assembly
1201
On-vehicle Inspection
1202
Removal
1202
Disassembly
1204
Inspection
1206
Assembly
1208
Installation
1211
Front Brake Hose Assembly
1212
Removal
1212
Installation
1213
Rear Disc Brake Assembly
1214
On-vehicle Inspection
1215
Removal
1215
Disassembly
1216
Inspection
1219
Assembly
1220
Installation
1224
Rear Brake Hose Assembly
1225
Removal
1225
Installation
1226
PARKING BRAKE
1227
GENERAL INFORMATION
1229
Parking Brake Assembly
1229
Description
1230
Specifications
1230
Tools
1231
Circuit Diagram
1232
DIAGNOSIS & TESTING
1233
Problem Symptoms Table
1233
ON-VEHICLE SERVICE
1234
Adjustment
1234
Parking Brake Switch Assembly
1235
On-vehicle Inspection
1235
Removal
1235
Inspection
1236
Installation
1236
Parking Brake Control Mechanism Assembly
1237
Removal
1237
Installation
1238
Parking Brake Rear Cable Assembly
1239
Removal
1239
Installation
1240
Rear Brake Assembly
1241
Removal
1242
Disassembly
1243
Inspection
1246
Assembly
1247
Installation
1247
STEERING COLUMN
1249
GENERAL INFORMATION
1251
Description
1251
Specifications
1253
Tools
1254
DIAGNOSIS & TESTING
1255
Problem Symptoms Table
1255
Steering Wheel Free Play Inspection
1257
Steering Wheel Centering/Returnability Inspection
1257
ON-VEHICLE SERVICE
1258
Steering Wheel Assembly
1258
Removal
1258
Inspection
1259
Installation
1260
Combination Switch Cover
1261
Removal
1261
Inspection
1262
Installation
1263
Steering Column with Intermediate Shaft Assembly (without EPS)
1264
Removal
1264
Disassembly
1266
Inspection
1267
Assembly
1267
Installation
1268
Electronic Power Steering Column with Intermediate Shaft Assembly
1269
Removal
1269
Disassembly
1271
Inspection
1271
Assembly
1271
Installation
1271
HYDRAULIC ASSIST STEERING
1273
GENERAL INFORMATION
1275
Description
1275
Operation
1276
Specifications
1277
Tool
1277
DIAGNOSIS & TESTING
1278
Problem Symptoms Table
1278
Steering Fluid Draining
1279
Steering Fluid Adding
1280
Bleeding Procedures
1281
ON-VEHICLE SERVICE
1282
Steering Fluid Reservoir Assembly
1282
Removal
1282
Inspection
1282
Installation
1283
Steering Fluid Pipe
1284
Removal
1284
Inspection
1288
Installation
1288
Power Steering Pump Assembly
1289
Removal
1289
Disassembly
1290
Inspection
1290
Assembly
1290
Installation
1290
Ball Pin Assembly
1291
Removal
1291
Inspection
1291
Installation
1292
Steering Tie Rod Assembly
1293
Removal
1293
Inspection
1293
Installation
1294
Steering Gear Assembly
1295
Removal
1295
Inspection
1297
Installation
1297
Steering Gear Clearance Adjustment
1298
ELECTRONIC POWER STEERING
1299
GENERAL INFORMATION
1301
Description
1301
Operation
1302
Specifications
1302
Tools
1302
Circuit Diagram
1304
EPS Controller Pin Definition
1305
DIAGNOSIS & TESTING
1306
Diagnosis Help
1306
Intermittent DTC Troubleshooting
1306
Ground Inspection
1306
Diagnostic Trouble Code (DTC) Chart
1307
C1301
1308
C1302
1308
C1307
1308
C1323
1308
C1332
1308
C1351
1308
C1352
1308
C1901
1310
C1902
1310
C1910
1315
ON-VEHICLE SERVICE
1320
Ball Pin Assembly
1320
Removal
1320
Inspection
1320
Installation
1320
Steering Tie Rod Assembly
1321
Removal
1321
Inspection
1321
Installation
1322
Steering Gear Assembly
1323
Removal
1323
Inspection
1324
Installation
1324
Steering Gear Clearance Adjustment
1325
AIR CONDITIONING
1327
GENERAL INFORMATION
1329
Description
1329
Specifications
1331
Tools
1333
Circuit Diagram
1334
DIAGNOSIS & TESTING
1341
Problem Symptoms Table
1341
Diagnosis Procedure
1343
A/C System Function
1345
DTC Confirmation Procedure
1347
Intermittent DTC Troubleshooting
1347
Ground Inspection
1347
Diagnostic Trouble Code (DTC) Chart
1348
B2133
1349
B2134
1349
B2120
1354
B2121
1354
B2126
1358
B2127
1363
B2135
1367
B2160
1371
B2163
1371
B2166
1376
B2169
1380
B2172
1385
ON-VEHICLE SERVICE
1389
On-vehicle Inspection
1389
Compressor Assembly Noise Inspection
1389
Refrigerant Leakage Inspection
1390
Refrigerant Recovering/Draining
1392
Vacuum Pumping
1393
Refrigerant Recharging
1393
Refrigerant Oil Recovering
1394
Refrigerant Oil Charging
1395
A/C Control Panel Assembly
1396
Removal
1396
Inspection
1397
Installation
1397
A/C Element
1398
Removal
1398
Installation
1398
Blower Assembly
1399
Removal
1399
Inspection
1399
Installation
1399
Blower Speed Resistor
1400
Removal
1400
Installation
1400
Inner/Outer Circulation Damper Motor
1401
Removal
1401
Installation
1401
Mode Damper Servo Motor
1402
Removal
1402
Installation
1402
Mix Damper Servo Motor
1403
Removal
1403
Installation
1403
HVAC Assembly
1404
Removal
1404
Disassembly
1406
Inspection
1416
Assembly
1419
Installation
1419
A/C Low Pressure Line
1420
Removal
1420
Installation
1421
A/C High Pressure Line
1422
Removal
1422
Installation
1424
Compressor Assembly
1425
Removal
1425
Installation
1427
Condenser Assembly (w/Receiver Drier)
1428
Removal
1428
Inspection
1429
Installation
1430
Mix Damper Servo Motor (Left - Automatic A/C)
1431
Removal
1431
Installation
1431
Room Temperature Sensor (for Automatic A/C)
1432
Removal
1432
Inspection
1433
Installation
1434
Outside Temperature Sensor (for Automatic A/C)
1435
Inspection
1435
Heater Core Sensor (for Automatic A/C)
1438
Inspection
1438
SUPPLEMENTAL RESTRAINT SYSTEM
1441
GENERAL INFORMATION
1443
Description
1443
Operation
1444
Specifications
1445
Tools
1446
Circuit Diagram
1447
DIAGNOSIS & TESTING
1450
SRS Control Module Assembly Terminal List
1450
DTC Confirmation Procedure
1450
Intermittent DTC Troubleshooting
1450
Ground Inspection
1451
Diagnosis Procedure
1451
Diagnostic Trouble Code (DTC) Chart
1454
B0001-11
1455
B0001-12
1455
B0001-1A
1455
B0001-1B
1455
B0001-1C
1455
B0010-11
1463
B0010-12
1463
B0010-1A
1463
B0010-1B
1463
B0010-1C
1463
B0070-11
1471
B0070-12
1471
B0070-1A
1471
B0070-1B
1471
B0070-1C
1471
B0072-11
1479
B0072-12
1479
B0072-1A
1479
B0072-1B
1479
B0072-1C
1479
B1231-12
1486
B1231-1C
1486
B1232-12
1491
B1232-1C
1491
B1210-00
1496
B1211-00
1496
B125A-00
1496
B1240-96
1496
B1251-49
1496
B1250-16
1497
B1250-17
1497
U1300-55
1502
ON-VEHICLE SERVICE
1504
Driver Airbag
1504
On-vehicle Inspection
1504
Removal
1505
Installation
1506
Disposal
1506
Spiral Cable
1507
Removal
1507
Inspection
1507
Installation
1508
Front Passenger Airbag
1509
On-vehicle Inspection
1509
Removal
1509
Installation
1511
Disposal
1511
SRS Control Module Assembly
1512
Removal
1512
Installation
1512
SEAT BELT
1513
GENERAL INFORMATION
1515
Description
1515
Operation
1517
Specifications
1517
Tool
1517
Circuit Diagram
1518
DIAGNOSIS & TESTING
1519
Seat Belt Inspection
1519
ON-VEHICLE SERVICE
1520
Front Seat Belt Assembly
1520
Removal
1520
Inspection
1521
Installation
1522
Front Seat Belt Buckle Assembly
1523
On-vehicle Inspection
1523
Removal
1524
Installation
1524
Height Adjuster Assembly
1525
Removal
1525
Installation
1525
Rear Seat Belt Assembly
1526
Removal
1526
Inspection
1527
Installation
1527
Center Seat Belt Assembly
1528
Removal
1528
Inspection
1529
Installation
1530
Rear Seat Belt Buckle Assembly
1531
Removal
1531
Installation
1532
ENGINE IMMOBILIZER
1533
GENERAL INFORMATION
1535
Description
1535
Operation
1535
Tools
1536
Circuit Diagram
1537
Immobilizer Control Module Terminal List
1538
DIAGNOSIS & TESTING
1539
Problem Symptoms Table
1539
Engine Immobilizer System Match
1539
Diagnostic Help
1542
Intermittent DTC Troubleshooting
1543
Ground Inspection
1543
Diagnostic Trouble Code (DTC) Chart
1543
B1300
1544
B1301
1545
B1302
1547
B1303
1548
B1304
1551
B1305
1554
B1306
1555
U0100
1556
U0073
1556
ON-VEHICLE SERVICE
1558
Immobilizer Control Module
1558
Removal & Installation
1558
LIGHTING SYSTEM
1559
GENERAL INFORMATION
1561
Light Position Diagram
1561
System Assembly Diagram
1563
Description
1564
Specifications
1564
Tools
1565
Circuit Diagram
1566
DIAGNOSIS & TESTING
1580
Problem Symptoms Table
1580
DTC Confirmation Procedure
1583
Intermittent DTC Troubleshooting
1583
Ground Inspection
1583
System Diagnosis
1584
Diagnosis Procedure
1586
Diagnostic Trouble Code (DTC) chart
1588
B100111
1589
B100113
1589
B100119
1589
B100211
1596
B100213
1596
B100219
1596
B100311
1603
B100313
1603
B100319
1603
B100411
1610
B100413
1610
B100419
1610
B100813
1617
B100871
1617
ON-VEHICLE SERVICE
1622
Headlight Adjustment Switch Assembly
1622
Removal
1622
Inspection
1623
Installation
1624
Combination Light Adjustment Switch
1625
Removal
1625
Inspection
1626
Installation
1626
Headlight Assembly
1627
Removal
1627
Installation
1628
Adjustment
1628
Rear Combination Light Assembly (Fixed Part)
1632
Removal
1632
Installation
1633
Rear Combination Light Assembly (Movable Part)
1634
Removal
1634
Installation
1635
Front Fog Light Assembly
1636
Removal
1636
Installation
1636
Rear Fog Light & Reflector Assembly
1637
Removal
1637
Installation
1637
Front Dome Light Assembly
1638
Removal
1638
Inspection
1639
Installation
1639
Rear Dome Light Assembly
1640
Removal
1640
Inspection
1641
Installation
1641
Front Door Courtesy Light
1642
Removal
1642
Installation
1642
High Mounted Stop Light Assembly
1643
Removal
1643
Installation
1643
License Plate Light Assembly
1644
Removal
1644
Installation
1644
Luggage Compartment Light Assembly
1645
Removal
1645
Installation
1645
Back-up Light Switch Assembly
1646
Removal
1646
Inspection
1646
Installation
1647
Hazard Warning Light Switch
1648
Removal
1648
Inspection
1648
Installation
1649
WIPER AND WASHER
1651
GENERAL INFORMATION
1653
Description
1653
Specifications
1655
Tool
1655
Circuit Diagram
1656
DIAGNOSIS & TESTING
1658
Problem Symptoms Table
1658
Diagnosis Tools
1659
DTC Confirmation Procedure
1659
Intermittent DTC Troubleshooting
1660
Ground Inspection
1660
Diagnosis Procedure
1660
Diagnostic Trouble Code (DTC) Chart
1662
B101471
1663
B101571
1663
B101671
1663
B101713
1663
B101771
1663
B101813
1663
B101871
1663
ON-VEHICLE SERVICE
1672
Wiper Switch Assembly
1672
Removal
1672
Inspection
1673
Installation
1673
Front Wiper Arm Assembly
1674
Removal
1674
Installation
1675
Front Wiper Motor Assembly
1676
Removal
1676
Inspection
1677
Installation
1678
Front Washer Nozzle Assembly
1679
Removal
1679
Inspection
1679
Installation
1680
Rear Wiper Arm Assembly
1681
Removal
1681
Installation
1682
Rear Wiper Motor Assembly
1683
Removal
1683
Inspection
1684
Installation
1684
Rear Washer Nozzle Assembly
1685
Removal
1685
Inspection
1685
Installation
1686
Washer Pump Assembly
1687
Removal
1687
Installation
1688
Inspection
1688
Washer Fluid Reservoir Assembly
1689
Removal
1689
Inspection
1690
Installation
1690
Washer Line Assembly
1691
Removal
1691
Installation
1692
Rain Gutter Rail Reinforcement Assembly
1693
Removal
1693
Installation
1694
DOOR LOCK
1695
GENERAL INFORMATION
1697
Description
1697
Specifications
1706
Tools
1707
Circuit Diagram
1708
DIAGNOSIS & TESTING
1711
Problem Symptoms Table
1711
Diagnosis Tools
1712
DTC Confirmation Procedure
1712
Intermittent DTC Troubleshooting
1713
Ground Inspection
1713
Diagnosis Procedure
1713
Diagnostic Trouble Code (DTC) Chart
1715
B101D11
1716
B101D13
1716
B101D12
1716
B102471
1721
B102711
1721
ON-VEHICLE SERVICE
1733
Engine Hood Lock Assembly
1733
Removal
1733
Installation
1734
Front Door Lock Assembly
1735
Removal
1735
Inspection
1736
Installation
1737
Front Door Key Cylinder
1738
Removal
1738
Installation
1739
Front Door Lock Striker Assembly
1740
Removal
1740
Installation
1740
Rear Door Lock Assembly
1741
Removal
1741
Inspection
1742
Installation
1743
Rear Door Lock Striker Assembly
1744
Removal
1744
Installation
1744
Back Door Lock Assembly
1745
Removal
1745
Inspection
1746
Installation
1746
Back Door Lock Striker Assembly
1747
Removal
1747
Installation
1747
Low Frequency Antenna
1748
Removal
1748
Installation
1751
Wireless Key
1752
Removal
1752
Installation
1754
INSTRUMENT CLUSTER
1755
GENERAL INFORMATION
1757
Description
1757
Operation
1758
Specification
1758
Tools
1758
Circuit Diagram
1759
Instrument Cluster Terminal List
1764
DIAGNOSIS & TESTING
1765
Problem Symptoms Table
1765
Diagnosis Tools
1767
DTC Confirmation Procedure
1767
Intermittent DTC Troubleshooting
1767
Ground Inspection
1768
Diagnosis Procedure
1768
Diagnostic Trouble Code (DTC) Chart
1770
B1100-13
1771
B1100-16
1771
B1100-17
1771
B1101-11
1775
B1101-15
1775
B1103-00
1779
B1104-41
1782
U0100-87
1783
U0101-87
1783
U0129-87
1783
U0131-87
1783
U0140-87
1783
U0151-87
1783
U0167-87
1783
U0214-87
1783
U0073-88
1783
U1300-55
1795
ON-VEHICLE SERVICE
1796
Instrument Cluster
1796
Removal
1796
Installation
1797
AUDIO SYSTEM
1799
GENERAL INFORMATION
1801
Description
1801
Operation
1802
Specifications
1802
Tool
1802
Circuit Diagram
1803
Audio System Control Module Terminal List
1807
DIAGNOSIS & TESTING
1809
Problem Symptoms Table
1809
ON-VEHICLE SERVICE
1810
No Disc DVD Assembly
1810
Removal
1810
Inspection
1811
Installation
1811
Tweeter Assembly
1812
Removal
1812
Inspection
1812
Installation
1812
Front Woofer Assembly
1813
Removal
1813
Inspection
1813
Installation
1814
Rear Woofer Assembly
1815
Removal
1815
Inspection
1815
Installation
1816
Antenna Assembly (w/ Antenna Amplifier)
1817
Removal
1817
Inspection
1818
Installation
1818
Multi-function Interface
1819
Removal
1819
Installation
1819
No Disc DVD Control Panel
1820
Removal
1820
Installation
1821
Steering Wheel Quick Button (if equipped)
1822
Removal
1822
Inspection
1824
Installation
1824
REVERSING RADAR SYSTEM
1825
GENERAL INFORMATION
1827
Description
1827
Operation
1827
Reversing Radar Normal Alarm Display
1828
Specification
1828
Tool
1828
Circuit Diagram
1829
Reversing Radar Control Module Assembly Terminal List
1832
DIAGNOSIS & TESTING
1833
Problem Symptoms Table
1833
Self-checking Function
1833
ON-VEHICLE SERVICE
1834
Reversing Radar Sensor
1834
Removal
1834
Installation
1835
Rear View Monitor Camera
1836
Removal
1836
Installation
1836
Reversing Radar Control Module Assembly
1837
Removal
1837
Installation
1837
HORN
1839
GENERAL INFORMATION
1841
Description
1841
Specification
1842
Tool
1842
Circuit Diagram
1843
DIAGNOSIS & TESTING
1844
Problem Symptoms Table
1844
Horn Fuse Inspection
1844
Horn Relay Inspection
1845
ON-VEHICLE SERVICE
1846
Horn
1846
Removal
1846
Inspection
1846
Installation
1847
OTHER SYSTEM
1849
GENERAL INFORMATION
1851
Description
1851
Circuit Diagram
1852
ON-VEHICLE SERVICE
1853
Cigarette Lighter Assembly
1853
Removal
1853
Installation
1854
Backup Power Supply Assembly
1855
Removal
1855
Installation
1856
WINDSHIELD/WINDOW GLASS
1857
GENERAL INFORMATION
1859
Description
1859
Specifications
1864
Tools
1865
Circuit Diagram
1866
DIAGNOSIS & TESTING
1869
Problem Symptoms Table
1869
Diagnosis Tools
1869
DTC Confirmation Procedure
1869
Intermittent DTC Troubleshooting
1870
Ground Inspection
1870
Diagnosis Procedure
1871
Diagnostic Trouble Code (DTC) Chart
1872
B100C13
1873
B100C71
1873
B100D13
1873
B100D71
1873
B100E13
1879
B100E71
1879
B100F13
1879
B100F71
1879
B101013
1886
B101071
1886
B101113
1886
B101171
1886
B101213
1893
B101271
1893
B101313
1893
B101371
1893
ON-VEHICLE SERVICE
1900
Power Glass Regulating Control Master Switch
1900
Removal
1900
Inspection
1901
Installation
1902
Front Door Outer Weather bar
1903
Removal
1903
Installation
1904
Front Door Glass Assembly
1905
Removal
1905
Installation
1906
Front Door Glass Rear Guide Rail Assembly
1907
Removal
1907
Installation
1908
Front Door Power Glass Regulator Assembly
1909
Removal
1909
Inspection
1910
Installation
1910
Power Glass Regulating Switch
1911
Removal
1911
Inspection
1913
Installation
1913
Rear Door Outer Weather bar
1914
Removal
1914
Installation
1914
Rear Door Glass Assembly
1915
Removal
1915
Installation
1916
Rear Door Glass Rear Guide Rail Assembly
1917
Removal
1917
Installation
1917
Rear Door Power Glass Regulator Assembly
1918
Removal
1918
Inspection
1919
Installation
1919
Triangular Window Glass Assembly
1920
Removal
1920
Installation
1922
Front Windshield Assembly
1926
Removal
1926
Installation
1928
Rear Windshield Assembly
1933
Removal
1933
Installation
1935
Rear Window Defroster
1939
General Information
1939
Circuit Diagram
1940
Rear Window Defroster System
1940
Problem Symptoms Table
1941
Rear Window Defogger Switch
1942
Removal
1942
Installation
1943
REAR VIEW MIRROR
1945
GENERAL INFORMATION
1947
Description
1947
Specifications
1948
Tool
1948
Circuit Diagram
1949
DIAGNOSIS & TESTING
1950
Problem Symptoms Table
1950
Repair & Inspection Items
1950
ON-VEHICLE SERVICE
1951
Outside Rear View Mirror Assembly
1951
Removal
1951
Inspection
1952
Installation
1952
Outside Rear View Mirror Housing Assembly
1953
Removal
1953
Installation
1953
Outside Rear View Mirror Lens Assembly
1954
Removal
1954
Installation
1954
Inside Rear View Mirror Assembly
1955
Removal
1955
Installation
1955
Rear View Mirror Adjustment Switch Assembly
1956
Removal
1956
Inspection
1957
Installation
1958
INSTRUMENT PANEL
1959
GENERAL INFORMATION
1961
Description
1961
Specifications
1965
Tools
1966
ON-VEHICLE SERVICE
1967
Auxiliary Fascia Console Assembly
1967
Removal
1967
Disassembly
1971
Assembly
1974
Installation
1974
Instrument Panel Assembly
1975
Removal
1975
Disassembly
1978
Assembly
1981
Installation
1981
Instrument Panel Crossmember Assembly
1982
Removal
1982
Installation
1985
SEAT
1987
GENERAL INFORMATION
1989
Description
1989
Driver Seat Assembly
1989
Front Passenger Seat Assembly
1991
Rear Seat Assembly
1993
Specifications
1995
Tool
1996
Circuit Diagram
1997
ON-VEHICLE SERVICE
1998
Front Seat Assembly
1998
Removal
1998
Disassembly
2000
Assembly
2008
Installation
2008
Inspection
2008
Rear Seat Assembly
2011
Removal
2011
Disassembly
2012
Assembly
2019
Installation
2020
Inspection
2020
Seat Heater Switch
2022
Removal
2022
Installation
2022
ENGINE HOOD/DOOR
2023
GENERAL INFORMATION
2025
Description
2025
Specifications
2031
Tool
2032
ON-VEHICLE SERVICE
2033
Hood Assembly
2033
Removal
2033
Installation
2035
Adjustment
2036
Inspection
2037
Hood Hinge Assembly
2038
Removal
2038
Installation
2039
Hood Cable Assembly
2040
Removal
2040
Installation
2042
Hood Air Spring Assembly
2043
Removal
2043
Installation
2044
Front Door Protector Assembly
2045
Removal
2045
Installation
2049
Front Door Assembly
2050
Removal
2050
Installation
2055
Adjustment
2055
Inspection
2057
Rear Door Protector Assembly
2058
Removal
2058
Installation
2060
Rear Door Assembly
2061
Removal
2061
Installation
2066
Adjustment
2066
Inspection
2068
Back Door Protector Assembly
2069
Removal
2069
Installation
2071
Back Door Assembly
2072
Removal
2072
Installation
2074
Adjustment
2075
Inspection
2077
Back Door Opener Switch Assembly
2078
Removal
2078
Installation
2078
Back Door Air Spring Assembly
2079
Removal
2079
Installation
2080
EXTERIOR
2081
GENERAL INFORMATION
2083
Description
2083
Specifications
2086
Tool
2087
ON-VEHICLE SERVICE
2088
Radiator Grille Assembly
2088
Removal
2088
Installation
2089
Water Tank Upper Crossmember Trim Board
2090
Removal
2090
Installation
2090
Front Bumper Assembly
2091
Removal
2091
Disassembly
2092
Assembly
2094
Installation
2095
Front Bumper Stiffener Bracket Assembly
2096
Removal
2096
Installation
2096
Front Bumper Mounting Bracket Assembly
2097
Removal
2097
Installation
2098
Front Bumper Crossmember Assembly
2099
Removal
2099
Installation
2099
Wheel Flare Assembly
2100
Removal
2100
Installation
2101
Apron Plate Assembly
2102
Removal
2102
Installation
2103
Front Wheel House Protector Assembly
2104
Removal
2104
Installation
2104
Fender Assembly
2105
Removal
2105
Installation
2108
Engine Lower Protector Assembly
2109
Removal
2109
Installation
2109
Rear Bumper Assembly
2110
Removal
2110
Disassembly
2112
Assembly
2113
Installation
2113
Rear Bumper Mounting Bracket Assembly
2114
Removal
2114
Installation
2114
Rear Bumper Crossmember Assembly
2115
Removal
2115
Installation
2116
Front Wheel House Protector Assembly of Rear Wheel
2117
Removal
2117
Installation
2117
Rear Wheel House Protector Assembly
2118
Removal
2118
Installation
2118
Front Windshield Lower Garnish Assembly
2119
Removal
2119
Installation
2120
Roof Rack Assembly
2121
Removal
2121
Installation
2122
Rear Spoiler Assembly
2123
Removal
2123
Installation
2124
Back Door Upper Trim Board Assembly
2125
Removal
2125
Installation
2127
Name Plate
2128
Removal
2128
Installation
2128
INTERIOR
2131
GENERAL INFORMATION
2133
Description
2133
Specifications
2138
Tool
2138
ON-VEHICLE SERVICE
2139
Front Door Scuff Plate Assembly
2139
Removal
2139
Installation
2139
Rear Door Scuff Plate Assembly
2140
Removal
2140
Installation
2140
Front Doorsill Pressure Plate Assembly
2141
Removal
2141
Installation
2141
Rear Doorsill Pressure Plate Assembly
2142
Removal
2142
Installation
2142
Back Doorsill Pressure Plate Assembly
2143
Removal
2143
Installation
2143
Front Door Opening Weatherstrip
2144
Removal
2144
Installation
2144
Rear Door Opening Weatherstrip
2145
Removal
2145
Installation
2145
Back Door Weatherstrip
2146
Removal
2146
Installation
2146
A-pillar Upper Protector Assembly
2147
Removal
2147
Installation
2148
A-pillar Lower Protector Assembly
2149
Removal
2149
Installation
2149
B-pillar Lower Protector Assembly
2150
Removal
2150
Installation
2150
B-pillar Upper Protector Assembly
2151
Removal
2151
Installation
2152
C-pillar Lower Protector Assembly
2153
Removal
2153
Installation
2155
C-pillar Upper Protector Assembly
2156
Removal
2156
Installation
2157
Sun Visor Assembly
2158
Removal
2158
Installation
2158
Passenger Grip Assembly
2159
Removal
2159
Installation
2159
Roof Assembly
2160
Removal
2160
Installation
2163
Front Floor Carpet Assembly
2164
Removal
2164
Installation
2165
Luggage Compartment Carpet Assembly
2166
Removal
2166
Installation
2166
Tonneau Cover Assembly
2167
Removal
2167
Installation
2167
Fuel Filler Cap Cable Assembly
2168
Removal
2168
Installation
2170
Rear Wheel House Sound Insulation Pad
2171
Removal
2171
Installation
2171
BODY DIMENSIONS
2173
GENERAL INFORMATION
2175
Description
2175
Engine Compartment Dimensions
2176
Body Opening Dimensions (Front View)
2177
Body Opening Dimensions (Side View)
2178
Body Opening Dimensions (Rear View)
2179
Body Opening Dimensions (Top View)
2180
Body Frame Dimensions
2181
Body Assembly Dimensions
2182
Front Body Assembly Dimensions
2183
Rear Body Assembly Dimensions
2192
WIRE HARNESS
2201
WIRE HARNESS INFORMATION
2203
General Information
2203
Description
2203
Circuit Diagram Information
2203
Circuit Diagram Instruction
2204
Electrical Troubleshooting
2207
Wire Harness Troubleshooting
2207
Voltage Test
2207
Circuit Continuity Test
2207
Short Circuit Test
2207
Electrical Troubleshooting Tools
2208
Electrical Repair
2209
Wire Harness Repair
2209
Fuse Replacement
2209
Electrical Components
2210
VEHICLE POWER DISTRIBUTION
2212
General Information
2212
Description
2212
Circuit Diagram
2213
Circuit Distribution
2213
VEHICLE GROUND DISTRIBUTION
2226
General Information
2226
Description
2226
Circuit Diagram
2227
Ground Distribution
2227
VEHICLE FUSE & RELAY
2233
General Information
2233
Description
2233
Fuse & Relay
2234
Engine Compartment Fuse and Relay Box
2234
Instrument Panel Fuse and Relay Box A
2236
Instrument Panel Fuse and Relay Box B
2237
VEHICLE WIRE HARNESS LAYOUT
2238
General Information
2238
Description
2238
Vehicle Wire Harness Layout
2239
Entire Vehicle Wire Harness Layout
2239
Engine Wire Harness
2240
Engine Compartment Wire Harness
2242
Instrument Panel Wire Harness
2245
Body Wire Harness
2248
Front Left Door Wire Harness
2252
Front Right Door Wire Harness
2253
Rear Right Door Wire Harness
2254
Rear Right Door Wire Harness
2255
Back Door Wire Harness
2256
A/C Wire Harness (for Electrical A/C System)
2257
A/C Wire Harness (for Automatic A/C System)
2258
Battery/Ground Wire Harness
2259
4
Based on 1 rating
Ask a question
Give review
Questions and Answers:
Need help?
Do you have a question about the Chery T21 2014 and is the answer not in the manual?
Ask a question
Chery T21 2014 Specifications
General
Brand
Chery
Model
T21 2014
Category
Automobile
Language
English
Related product manuals
Chery Tiggo 5 T21
253 pages
Chery TIGGO
152 pages
Chery Automobile
148 pages
Chery QQ
635 pages
Chery A3
105 pages
Chery QQ6
169 pages
Chery V5
216 pages
Chery A113
281 pages
Chery A5 2007
25 pages
Chery A1 2009
1080 pages
Chery A11 2003
784 pages
Chery J11
152 pages
