Chery Automobile Co., Ltd.
46 - SEAT
46–21
46
16.Remove the passenger side seat belt reminder (for front passenger side).
a. Remove 4 hog rings from the seat cushion assembly.
b. Remove the passenger side seat belt reminder (1).
17.Remove the seat track assembly (for front passenger side).
a. Remove 3 fixing bolts (arrow) from the left seat track
assembly.
ï€
(Tightening torque: 24 ± 2.4 N·m)
b. Remove 3 fixing bolts (arrow) from the right seat track
assembly, and remove the front passenger seat track
assembly.
ï€
(Tightening torque: 24 ± 2.4 N·m)
To Next Page
