DescriptionField
When this check box is checked, the information about the original recipient
of the call displays in the notification window.
Example: If Caller A calls B, but B has forwarded all calls to C and C has
forwarded all calls to D, then the notification box that D sees contains the
phone information for caller B.
By default, this check box is checked.
Dialed Number
Step 4
Select Save.
Enable BLF for Call Lists
The BLF for Call Lists field also controls the Line Status for Corporate Directory feature.
Procedure
Step 1
In the Cisco Unified Communications Manager Administration, select System > Enterprise Parameters.
Step 2
For the BLF for Call Lists field, enable or disable the feature.
By default, the feature is disabled.
Parameters that you set in the Product Specific Configuration area may also appear in the Device Configuration
window for various devices and in the Enterprise Phone Configuration window. If you set these same parameters
in these other windows as well, the setting that takes precedence is determined in the following order:
1
Device Configuration window settings
2
Common Phone Profile window settings
3
Enterprise Phone Configuration window settings
Step 3
Select Save.
Set Up Energy Efficient Ethernet for Switch and PC Port
IEEE 802.3az Energy Efficient Ethernet (EEE) is an extension of the IEEE 802.3 standard that provides a
method for reducing energy usage without reducing the vital function of network interfaces. Configurable
EEE enables the administrator to control EEE functions on personal computer port and switch port.
Administrators must confirm that the Override Check box is checked on all applicable UCM pages or
EEE will not function.
Note
The administrator controls the EEE functions with the following two parameters:
Cisco IP Phone 8800 Series Administration Guide for Cisco Unified Communications Manager
164
Phone Feature Configuration
