DescriptionItem
Neighbor device port to which the phone is connected discovered by CDP
protocol.
CDP Neighbor Port
Identifier of a device connected to this port discovered by LLDP
discovered.
LLDP Neighbor Device ID
IP address of the neighbor device that LLDP protocol discovered.LLDP Neighbor IPv6 address
Neighbor device port to which the phone connects that LLDP protocol
discovered.
LLDP Neighbor Port
Speed and duplex information.Port Information
Device Logs
The following Device log hyperlinks on a phone web page provide information that helps to monitor and
troubleshoot the phone.
•
Console logs: Includes hyperlinks to individual log files. The console log files include debug and error
messages that the phone received.
•
Core dumps: Includes hyperlinks to individual dump files. The core dump files include data from a
phone crash.
•
Status messages: Displays the 10 most recent status messages that the phone has generated since it last
powered up. The Status Messages screen on the phone also displays this information.
•
Debug display: Displays debug messages that might be useful to Cisco TAC if you require assistance
with troubleshooting.
Streaming Statistics
A Cisco Unified IP Phone can stream information to and from up to three devices simultaneously. A phone
streams information when it is on a call or is running a service that sends or receives audio or data.
The Streaming statistics areas on a phone web page provide information about the streams.
The following table describes the items in the Streaming Statistics areas.
Table 44: Streaming Statistics area items
DescriptionItem
IP address and UDP port of the destination of the stream.Remote address
IP address and UPD port of the phone.Local address
Internal time stamp indicates when Cisco Unified Communications Manager
requested that the phone start transmitting packets.
Start time
Cisco IP Phone 8800 Series Administration Guide for Cisco Unified Communications Manager
229
Cisco IP Phone Web Page
