Cisco 8811 Administration Guide

Network and Computer Port Pinouts
Although both the network and computer (access) ports are used for network connectivity, they serve different
purposes and have different port pinouts.
•
The network port is the 10/100/1000 SW port on the Cisco IP Phone.
•
The computer (access) port is the 10/100/1000 PC port on the Cisco IP Phone.
Network Port Connector
The following table describes the network port connector pinouts.
Table 6: Network Port Connector Pinouts
FunctionPin Number
BI_DA+1
BI_DA-2
BI_DB+3
BI_DC+4
BI_DC-5
BI_DB-6
BI_DD+7
BI_DD-8
BI stands for bidirectional, while DA, DB, DC, and DD stand for Data A, Data B, Data C, and Data
D respectively.
Note
Computer Port Connector
The following table describes the computer port connector pinouts.
Table 7: Computer (Access) Port Connector Pinouts
FunctionPin Number
BI_DB+1
BI_DB-2
BI_DA+3
Cisco IP Phone 8800 Series Administration Guide for Cisco Unified Communications Manager
9
Cable Specifications

Cisco 8811 Specifications

General

Ethernet Ports	2 x 10/100/1000
Lines Supported	5
Speakerphone	Yes
Headset Port	Yes
USB Port	No
Bluetooth	No
Wi-Fi	No
Resolution	800 x 480 pixels
PoE	Yes, IEEE 802.3af Class 2
Audio Codec Support	G.711, G.722, G.729, iLBC
Protocols	SIP
Display	5-inch, 800 x 480 pixels
Headset Jack	RJ9
Weight	1.1 kg
