Cisco 8811 Administration Guide

The Load Server is configured from the Enterprise Phone Configuration window. From Cisco Unified
Communications Manager Administration, choose Device > Phone >Enterprise Phone Configuration.
Set Up IPv4
The following table describes the IPv4 Setup menu options.
Table 13: IPv4 Setup Menu Options
To changeDescriptionOption
See Set DHCP Enabled Field,
on page 62.
Indicates whether the phone has DHCP enabled or
disabled.
When DHCP is enabled, the DHCP server assigns
the phone an IP address. When DHCP is disabled,
the administrator must manually assign an IP
address to the phone.
For more information, see Set Up Phone to Use
DHCP, on page 64 and Set Up Phone to Not Use
DHCP, on page 65.
DHCP Enabled
See Set IP Address Field, on
page 63.
Internet Protocol (IP) address of the phone.
If you assign an IP address with this option, you
must also assign a subnet mask and default router.
See the Subnet Mask and Default Router options
in this table.
IP Address
See Set Subnet Mask Field, on
page 63.
Subnet mask used by the phone.Subnet Mask
See Set Default Router Field,
on page 63.
Default router used by the phone.Default Router
See Set DNS Server Fields, on
page 63.
Primary Domain Name System (DNS) server (DNS
Server 1) and optional backup DNS servers (DNS
Server 2 and 3) that the phone uses.
DNS Server 1
DNS Server 2
DNS Server 3
See Set Alternate TFTP Field,
on page 64.
Indicates whether the phone is using an alternate
TFTP server.
Alternate TFTP
Cisco IP Phone 8800 Series Administration Guide for Cisco Unified Communications Manager
53
Configure Network Settings

Cisco 8811 Specifications

General

Ethernet Ports	2 x 10/100/1000
Lines Supported	5
Speakerphone	Yes
Headset Port	Yes
USB Port	No
Bluetooth	No
Wi-Fi	No
Resolution	800 x 480 pixels
PoE	Yes, IEEE 802.3af Class 2
Audio Codec Support	G.711, G.722, G.729, iLBC
Protocols	SIP
Display	5-inch, 800 x 480 pixels
Headset Jack	RJ9
Weight	1.1 kg
