Cisco ASR 1000 Series Aggregation Services Routers SIP and SPA Software Configuration Guide
OL-14127-08
Chapter 7 Configuring the ATM SPAs
Configuration Tasks
To create a range of PVCs on a multipoint subinterface, use the following procedure beginning in global
configuration mode:
Command or Action Purpose
Step 1
Router(config)# interface atm
slot/subslot/port.subinterface multipoint
Creates the specified point-to-multipoint subinterface on
the given port on the specified ATM SPA, and enters
subinterface configuration mode, where:
• slot—Specifies the chassis slot number in the Cisco
ASR 1000 Series Router where the SIP is installed.
• subslot—Specifies the secondary slot of the SIP
where the SPA is installed.
• port—Specifies the number of the individual
interface port on a SPA.
• subinterface—Specifies the number of the
subinterface.
Step 2
Router(config-subif)# range [range-name] pvc
[start-vpi/]start-vci [end-vpi/]end-vci
Configures multiple PVCs in the specified range and
enters ATM PVC range configuration mode, where:
• range-name—(Optional) Identifies this PVC range
with a text string.
• start-vpi—(Optional) Specifies the beginning VPI
ID in the range from 0 to 255. The default is 0.
• start-vci—Specifies the beginning VCI ID. The
valid range is 32 to 65535. Values 1 to 31 are
reserved and should not be used.
• end-vpi—(Optional) Specifies the ending VPI ID in
the range from 0 to 255. If you don’t specify an
end-vpi value, the end-vpi value defaults to the
start-vpi value.
• end-vci—Specifies the ending VCI ID. The valid
range is 32 to 65535. Values 1 to 31 are reserved and
should not be used.
Step 3
Once you configure the PVC range, you can configure other commands, such as the protocol command, for all
PVCs in the specified range, and you also can go on to define options for individual PVCs using the pvc-in-range
Step 4
Router(config-if-atm-range-pvc)# pvc-in-range [name]
[vpi/vci]
(Optional) Defines an individual PVC within a PVC
range, where:
• name—(Optional) Identifies a name for the PVC.
The PVC name can have a maximum of 15
characters.
• vpi/vci—(Optional) VPI for this PVC, from 0 to 255.
The default is 0. The VCI value can be in range from
32 to 65535.
Step 5
Once you specify a specific PVC in the range, you can continue to configure options that are specific to that PVC,
such as the class-vc command.
Step 6
Router(config-if-atm-vc-range-pvc)# end Exits ATM PVC range configuration mode and returns to
privileged EXEC mode.
