Cisco ASR 1000 Configuration Guide

27-16
Cisco ASR 1000 Series Aggregation Services Routers SIP and SPA Software Configuration Guide
OL-14127-08
Chapter 27 Classifying and Scheduling Packets for ASR 1000 Series
Information About Ingress Scheduling
DETAILED STEPS
Information About Ingress Scheduling
The following sections provide details regarding the Ingress Scheduling feature:
• Scheduling Overview, page 27-17
• Intra-CC Scheduling, page 27-17
Command or Action Purpose
Step 1
enable
Example:
Router> enable
Enables privileged EXEC mode. Enter your password when
prompted.
Step 2
configure terminal
Example:
Router# configure terminal
Enters global configuration mode.
Step 3
interface gigabitEthernet 0/0/0.1
Example:
Router(config)# interface gigabitEthernet
0/0/0.1
Enters the subinterface mode for Gigabit Ethernet 0/0/0.1.
Step 4
plim qos input map cos inner-based
Example:
Router(config-subif)# plim qos input map cos
inner-based
Enables and allows configuration for inner VLAN COS
values.
Note The VLAN COS values can be enabled by default
by executing the plim qos input map enable
command.
Step 5
plim qos input map cos inner 5 6 queue
strict-priority
Example:
Router(config-subif)# plim qos input map cos
inner 5 6 queue strict-priority
Configures the COS values or the range of the inner VLAN
of a qinq subinterface to high priority.
Step 6
plim qos input map cos outer-based
Example:
Router(config-subif)# plim qos input map cos
outer-based
Enables configuration for outer VLAN COS values.
Note The VLAN COS values can be enabled by default
by executing the command plim qos input map
enable.
Step 7
plim qos input map cos outer 4 queue
strict-priority
Example:
Router(config-subif)# plim qos input map cos
outer 4 queue strict-priority
Configures the COS values or range for outer-vlan of a qinq
sub-interface to high-priority.
