Cisco ASR 1000 Series Aggregation Services Routers SIP and SPA Software Configuration Guide
OL-14127-08
Chapter 6 Overview of the ATM SPAs
Displaying the SPA Hardware Type
Table 6-1 shows the hardware description that appears in the show interfaces command output for each
ATM SPA that is supported on the Cisco ASR 1000 Series Routers:
Example of the show interfaces Command
The following example shows output from the show interfaces atm command on a Cisco ASR 1000
Series Routers with an ATM SPA installed in the second subslot of a SIP that is installed in slot 0:
Router#show interfaces atm 0/2/2
ATM0/2/2 is up, line protocol is up
Hardware is SPA-3XOC3-ATM-V2, address is 001a.3044.7522 (bia 001a.3044.7522)
MTU 4470 bytes, sub MTU 4470, BW 149760 Kbit, DLY 80 usec,
reliability 255/255, txload 1/255, rxload 1/255
Encapsulation ATM, loopback not set
Keepalive not supported
Encapsulation(s): AAL5 AAL0
4095 maximum active VCs, 1 current VCCs
VC Auto Creation Disabled.
VC idle disconnect time: 300 seconds
4 carrier transitions
Last input never, output 00:04:11, output hang never
Last clearing of "show interface" counters never
Input queue: 0/375/0/0 (size/max/drops/flushes); Total output drops: 0
Queueing strategy: fifo
Output queue: 0/40 (size/max)
5 minute input rate 0 bits/sec, 0 packets/sec
5 minute output rate 0 bits/sec, 0 packets/sec
5 packets input, 540 bytes, 0 no buffer
Received 0 broadcasts (0 IP multicasts)
0 runts, 0 giants, 0 throttles
0 input errors, 0 CRC, 0 frame, 0 overrun, 0 ignored, 0 abort
5 packets output, 540 bytes, 0 underruns
0 output errors, 0 collisions, 1 interface resets
0 output buffer failures, 0 output buffers swapped out
Example of the show controllers Command
The following example shows output from the show controllers atm command on a Cisco ASR 1000
Series Routers with an ATM SPA installed in the second subslot of a SIP that is installed in slot
0:
Router# show controllers atm 0/2/2
Interface ATM0/2/2 (SPA-3XOC3-ATM-V2[0/2]) is up
Framing mode: SONET OC3 STS-3c
SONET Subblock:
SECTION
LOF = 0 LOS = 1 BIP(B1) = 0
LINE
AIS = 0 RDI = 1 FEBE = 55 BIP(B2) = 0
PATH
AIS = 0 RDI = 1 FEBE = 21 BIP(B3) = 0
Ta b l e 6-1 ATM SPA Hardware Descriptions in show interfaces Command
SPA Description in show interfaces Command
SPA-1XOC3-ATM-V2 “Hardware is SPA-1XOC3-ATM-V2”
SPA-3XOC3-ATM-V2 “Hardware is SPA-3XOC3-ATM-V2”
SPA-1XOC12-ATM-V2 “Hardware is SPA-1XOC12-ATM-V2”
