7-23
Cisco ASR 1000 Series Aggregation Services Routers SIP and SPA Software Configuration Guide
OL-14127-08
Chapter 7 Configuring the ATM SPAs
Configuration Tasks
PATH TRACE BUFFER : STABLE
BER thresholds: SF = 10e-3 SD = 10e-6
TCA thresholds: B1 = 10e-6 B2 = 10e-6 B3 = 10e-6
Clock source: line
Configuring AToM VP Cell Mode Relay Support
To configure Any Transport over MPLS (AToM) Cell Mode Relay, perform the following procedure
beginning in global configuration mode:
VP Mode Configuration Guidelines
When configuring ATM Cell Relay over MPLS in VP mode, use the following guidelines:
You do not need to enter the encapsulation aal0 command in VP mode, but only AAL0
encapsulation is supported with MPLS l2transport.
One ATM interface can accommodate multiple types of ATM connections. VP cell relay and VC cell
relay can coexist on one ATM interface.
If a VPI is configured for VP cell relay, you cannot configure a PVC using the same VPI.
VP trunking (mapping multiple VPs to one emulated VC label) is not supported in this release.
Each
VP is mapped to one emulated VC.
Each VP is associated with one unique emulated VC ID. The AToM emulated VC type is ATM VP
Cell Transport.
The AToM control word is supported. However, if a peer PE does not support the control word, it is
disabled. This negotiation is done by LDP label binding.
VP mode (and VC mode) drop idle cells.
VP Mode Configuration Example
The following example transports single ATM cells over a virtual path:
Router(config)# pseudowire-class vp-cell-relay
Command or Action Purpose
Step 1
Router(config)# interface atm
slot/subslot/port.subinterface multipoint
Enters interface configuration mode for the indicated port on the
specified ATM SPA
Step 2
Router(config-if)# no ip address ip-address mask Removes the IP address that is assigned to this interface (if one
has been configured).
Step 3
Router(config-if)# atm pvp vpi l2transport Creates a permanent virtual path (PVP) used to multiplex (or
bundle) one or more virtual circuits (VCs).
Step 4
Router(config-if)# xconnect peer-ip-address
vc-id {encapsulation mpls | pw-class
pw-class-name}
Routes Layer 2 packets over a specified point-to-point VC by
using ATM over multiprotocol label switching (AToM).
Step 5
Router(config-if)# end Exits interface configuration mode and returns to privileged
EXEC mode.
