Chapter 26 Upgrading Field-Programmable Devices
Troubleshooting Problems with FPD Image Upgrades
Nov.28 11:31:11:%SPA_OIR-3-HW_INIT_TIMEOUT:subslot 0/1
Nov.28 11:31:16:%SPA_OIR-3-RECOVERY_RELOAD:subslot 0/1:Attempting
recovery by reloading SPA
Nov.28 11:31:31:%SPA_OIR-3-HW_INIT_TIMEOUT:subslot 0/1
Nov.28 11:31:31:%SPA_OIR-3-SPA_POWERED_OFF:subslot 0/1:SPA 4xOC3 POS
SPA powered off after 5 failures within 600 seconds
The show hw-module all fpd command can be used to verify that the SPA is using a corrupted FPD
image. In this example, the SPA in slot 0/1 is corrupted.
Router# show hw-module all fpd
==== ====================== ====== =============================================
H/W Field Programmable Current Min. Required
Slot Card Type Ver. Device: "ID-Name" Version Version
==== ====================== ====== ================== =========== ==============
0/0 SPA-4XOC3-POS 1.0 1-I/O FPGA 3.4 3.4
---- ---------------------- ------ ------------------ ----------- --------------
0/1 SPA-4XOC3-PO<DISABLED> 1.0 ???????????? ?.? ?.?
---- ---------------------- ------ ------------------ ----------- --------------
0/2 SPA-1X10GE-L-V2 1.0 1-10GE I/O FPGA 1.9 1.9
---- ---------------------- ------ ------------------ ----------- --------------
0/3 SPA-1X10GE-L-V2 1.0 1-10GE I/O FPGA 1.9 1.9
==== ====================== ====== =================================================
Performing an FPD Recovery Upgrade
The recovery upgrade procedure can only be performed on a SPA that has been powered off by the
system after it has failed all of the retries attempted to initialize the SPA.
The following example displays the output of an attempt to perform a recovery upgrade before all the
initialization retries have been attempted for the SPA in subslot 0/1.
Note Because a recovery upgrade is done at a more conservative speed, it may take more than the estimated
upgrade time.
Note Other factors can cause the system to ask “Do you want to perform the recovery upgrade operation?”
Only answer y to this question if you have attempted an FPD upgrade that has failed due to a power
failure or a SPA removal.

If you are prompted for this question without having previously had a failed upgrade attempt for one of
the aforementioned reasons, contact Cisco Technical Support.
Nov.28 11:29:55:%SPA_OIR-3-RECOVERY_RELOAD:subslot 0/1:Attempting
recovery by reloading SPA
Nov.28 11:30:10:%SPA_OIR-3-HW_INIT_TIMEOUT:subslot 0/1
Nov.28 11:30:15:%SPA_OIR-3-RECOVERY_RELOAD:subslot 0/1:Attempting
recovery by reloading SPA
Nov.28 11:30:31:%SPA_OIR-3-HW_INIT_TIMEOUT:subslot 0/1
Router# upgrade hw-module subslot 0/1 fpg bundled
% Cannot get FPD version information for version checking. If a previous
upgrade attempt has failed for the target card, then a recovery upgrade
would be required to fix the failure.
% The following FPD(s) will be upgraded for SPA-4XOC3-POS (H/W ver =
1.0) in subslot 0/1:
