23-14
Cisco ASR 1000 Series Aggregation Services Routers SIP and SPA Software Configuration Guide
OL-14127-08
Chapter 23 Troubleshooting the Cisco WebEx Node for the ASR 1000 Series
Performing Basic Troubleshooting
Using the ping Command from the Cisco ASR1000 Series Router to Verify
Network Connectivity
Note The Cisco WebEx Node SPA might not activate properly if network access between the Cisco ASR
Series 1000 Aggregation Services Router and certain Cisco WebEx servers is blocked, such as the Cisco
WebEx Data Center SSL Gateway or Cisco WebEx Node Management server. Be sure to verify
connectivity to these servers from the Cisco ASR 1000 Series Router.
Network connectivity
problem, such as the subnet
assigned to the
service-engine interface is
not routable.
• The output from the show
hw-module subslot service-engine
status command shows “Offline” in
the Application Status field.
• Confirm that a message similar to the
following example appears on the RP
console:
Nov 3 13:45:51.943:
%SPA_SRVCS_ENGINE-3-APP_MSG_ERR:
SIP0/0: SPA-WMA-K9[0/1]: Connect
CWNMS server failed, check
network availability to CWNMS
server.
1. Check network connectivity to the Cisco
WebEx Data Center, using the traceroute
command from the Cisco WebEx SPA console
as shown in the following example:
service-spa# traceroute wma.webex.com
traceroute to globalwatch.webex.com
(10.114.169.228), 30 hops max, 38 byte
packets
1 10.1.1.1 (12.1.1.1) 0.277 ms 0.254 ms
0.246 ms
2 10.1.99.65 (10.1.99.65) 0.577 ms 0.394
ms 0.387 ms
2. Check network connectivity from the clients
that will be joining the meeting being hosted on
the Cisco WebEx Node SPA. Use the ping
command from the Cisco WebEx SPA console
as shown in the following example, where
172.16.144.153 is address of the client:
service-spa# ping 172.16.144.153
PING 172.16.144.153 (172.16.144.153)
100(128) bytes of data.
108 bytes from 172.16.144.153: icmp_seq=1
ttl=41 time=69.1 ms
108 bytes from 172.16.144.153: icmp_seq=2
ttl=41 time=68.9 ms
108 bytes from 172.16.144.153: icmp_seq=3
ttl=41 time=68.8 ms
108 bytes from 172.16.144.153: icmp_seq=4
ttl=41 time=68.9 ms
108 bytes from 172.16.144.153: icmp_seq=5
ttl=41 time=68.9 ms
--- 172.16.144.153 ping statistics ---
5 packets transmitted, 5 received, 0% packet
loss, time 4000ms
rtt min/avg/max/mdev =
68.882/68.976/69.133/0.299 ms
For more information about accessing the Cisco
WebEx SPA console, see the
“Accessing the Cisco
WebEx Node SPA Console” section on page 23-4.
Table 23-3 Possible Reasons for Application Status Problems for the Cisco WebEx Node SPA (continued)
Possible Problem Observations and Comments Solutions
