Cisco ASR 1000 Configuration Guide

17-10
Cisco ASR 1000 Series Aggregation Services Routers SIP and SPA Software Configuration Guide
OL-14127-08
Chapter 17 Configuring the 2-Port and 4-Port Clear Channel T3/E3 SPAs
Configuration Tasks
Verifying Scramble Configuration
Use the show controllers serial command to display the scrambling setting:
Router# show controllers serial 2/0/0
Serial2/0/0 -
Framing is c-bit, Clock Source is Line
Bandwidth limit is 44210, DSU mode 0, Cable length is 10
rx FEBE since last clear counter 2, since reset 0
Scrambling is enabled
Data in current interval (356 seconds elapsed):
0 Line Code Violations, 0 P-bit Coding Violation
0 C-bit Coding Violation
0 P-bit Err Secs, 0 P-bit Sev Err Secs
0 Sev Err Framing Secs, 0 Unavailable Secs
0 Line Errored Secs, 0 C-bit Errored Secs, 0 C-bit Sev Err Secs
Data in Interval 1:
0 Line Code Violations, 0 P-bit Coding Violation
0 C-bit Coding Violation
0 P-bit Err Secs, 0 P-bit Sev Err Secs
0 Sev Err Framing Secs, 0 Unavailable Secs
0 Line Errored Secs, 0 C-bit Errored Secs, 0 C-bit Sev Err Secs
Command Purpose
Router# configure terminal Enters global configuration mode.
Router(config)# interface serial slot/subslot/port Selects the interface to configure and enters
interface configuration mode.
• slot/subslot/port—Specifies the location of the
interface. See the
“Specifying the Interface
Address on a SPA” section on page 17-5.
Router(config-if)# [no] scramble Enables scrambling. Scrambling is disabled by
default.
• scramble—Enables scramble.
• no scramble—Disables scramble.
Note When using framing bypass, no
scrambling must be configured.

Cisco ASR 1000 Specifications

General

Operating System	Cisco IOS XE
Interfaces	10 Gigabit Ethernet
Power Supply	AC or DC
Number of Total Expansion Slots	Varies by model
Management Port	Console
Redundant Power Supply Supported	Yes
Width	17.5 inches
Memory	Varies by model
Storage	Varies by model
Dimensions (H x W x D)	Varies by model
Weight	Varies by model
Operating Temperature	32°F to 104°F (0°C to 40°C)
Humidity	5% to 95% non-condensing
MTBF	Varies by model
Redundancy	Redundant power supplies, fans, and route processors (depending on model)
