Cisco Catalyst 2950 Command Reference

2-83
Catalyst 2950 and Catalyst 2955 Switch Command Reference
OL-10102-01
Chapter 2 Catalyst 2950 and 2955 Cisco IOS Commands
deny (access-list configuration)
Defaults There are no specific conditions that deny packets in the named or numbered IP ACL.
The default ACL is always terminated by an implicit deny statement for all packets.
Command Modes Access-list configuration
Command History
Usage Guidelines Use this command after the ip access-list global configuration command to specify deny conditions for
an IP ACL. You can specify a source IP address, destination IP address, IP protocol, TCP port, or UDP
port. Specify the TCP and UDP port numbers only if protocol is tcp or udp and operator is eq.
Note For more information about configuring IP ACLs, see the “Configuring Network Security with ACLs”
chapter in the software configuration guide for this release.
Examples This example shows how to create an extended IP ACL and to configure deny conditions for it:
Switch(config)# ip access-list extended Internetfilter
Switch(config-ext-nacl)# deny tcp host 190.5.88.10 any
Switch(config-ext-nacl)# deny tcp host 192.1.10.10 any
operator port (Optional) Define a source or destination port.
The operator can be only eq (equal).
If operator is after the source IP address and wildcard, conditions match
when the source port matches the defined port.
If operator is after the destination IP address and wildcard, conditions
match when the destination port matches the defined port.
The port is a decimal number or name of a TCP or User Datagram
Protocol (UDP) port. The number can be from 0 to 65535.
Use TCP port names only for TCP traffic.
Use UDP port names only for UDP traffic.
dscp dscp-value (Optional) Define a Differentiated Services Code Point (DSCP) value to
classify traffic.
For the dscp-value, enter any of the 13 supported DSCP values (0, 8, 10,
16, 18, 24, 26, 32, 34, 40, 46, 48, and 56), or use the question mark (?) to
see a list of available values.
time-range
time-range-name
(Optional) For the time-range keyword, enter a meaningful name to
identify the time range. For a more detailed explanation of this keyword,
see the software configuration guide.
Release Modification
12.1(6)EA2 This command was introduced.

Cisco Catalyst 2950 Specifications

General

Forwarding Bandwidth	8.8 Gbps
Switching Capacity	13.6 Gbps
Forwarding Rate	6.6 Mpps
Weight	3.6 kg
RAM	16 MB
Flash Memory	8 MB
Operating Humidity	10% to 85% non-condensing
Uplink Ports	2 x 10/100/1000Base-T
Dimensions	4.4 cm x 44.5 cm x 24.2 cm
Remote Management Protocol	SNMP, Telnet, HTTP
Features	Quality of Service (QoS), VLAN support
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p
Status Indicators	system
Operating Temperature	0 to 45°C
Ports	24 x 10/100 Ethernet ports
MAC Address Table Size	8, 192 entries
Power Supply	Internal 100-240V AC, 50-60Hz
