Cisco Catalyst 2950 Command Reference

2-434
Catalyst 2950 and Catalyst 2955 Switch Command Reference
0L-10102-01
Chapter 2 Catalyst 2950 and 2955 Cisco IOS Commands
snmp-server host
snmp-server host
Use the snmp-server host global configuration command to specify the recipient (host) of a Simple
Network Management Protocol (SNMP) notification operation. Use the no form of this command to
remove the specified host.
snmp-server host host-addr [informs | traps] [version {1 | 2c | 3 {auth | noauth | priv}}]
community-string [alarms] [bridge] [c2900] [cluster] [config] [copy-config] [entity]
[envmon] [flash] [hsrp] [mac-notification] [port-security] [rtr] [snmp] [stpx] [syslog] [tty]
[udp-port port-number] [vlan-membership] [vlancreate] [vlandelete] [vtp]
no snmp-server host host-addr [informs | traps] [version {1 | 2c | 3 {auth | noauth | priv}}]
community-string
Syntax Description host-addr Name or Internet address of the host (the targeted recipient).
informs | traps (Optional) Send SNMP traps or informs to this host.
version {1 | 2c | 3} (Optional ) Version of SNMP used to send the traps.
These keywords are supported:
1—SNMPv1. This option is not available with informs.
2c—SNMPv2C.
3—SNMPv3. These optional keywords can follow the version 3 keyword:
• auth (Optional). Enables Message Digest 5 (MD5) and Secure Hash
Algorithm (SHA) packet authentication.
•
•
priv (Optional). Enables Data Encryption Standard (DES) packet
encryption (also called privacy). The priv keyword is available only
when the cryptographic (encrypted) software image is installed.
community-string Password-like community string sent with the notification operation.
Though you can set this string by using the snmp-server host command,
we recommend that you define this string by using the snmp-server
community global configuration command before using the snmp-server
host command.
alarms (Optional) Send SNMP alarm traps. This keyword is only available on a
Catalyst 2955 switch.
bridge (Optional) Send SNMP STP bridge MIB traps.
c2900 (Optional) Send SNMP switch traps.
cluster (Optional) Send cluster member status traps.
config (Optional) Send SNMP configuration traps.
copy-config (Optional) Send SNMP copy-configuration traps.
entity (Optional) Send SNMP entity traps.
envmon (Optional) Send enviromental monitor (EnvMon) traps.
flash (Optional) Send SNMP FLASH notifications.
hsrp (Optional) Send Hot Standby Router Protocol (HSRP) traps.
mac-notification (Optional) Send MAC notification traps.

Cisco Catalyst 2950 Specifications

General

Forwarding Bandwidth	8.8 Gbps
Switching Capacity	13.6 Gbps
Forwarding Rate	6.6 Mpps
Weight	3.6 kg
RAM	16 MB
Flash Memory	8 MB
Operating Humidity	10% to 85% non-condensing
Uplink Ports	2 x 10/100/1000Base-T
Dimensions	4.4 cm x 44.5 cm x 24.2 cm
Remote Management Protocol	SNMP, Telnet, HTTP
Features	Quality of Service (QoS), VLAN support
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p
Status Indicators	system
Operating Temperature	0 to 45°C
Ports	24 x 10/100 Ethernet ports
MAC Address Table Size	8, 192 entries
Power Supply	Internal 100-240V AC, 50-60Hz
