Cisco Catalyst 2950 Command Reference

2-324
Catalyst 2950 and Catalyst 2955 Switch Command Reference
0L-10102-01
Chapter 2 Catalyst 2950 and 2955 Cisco IOS Commands
show dot1x
BendSM State = IDLE
ReAuthPeriod = 4000 Seconds { (From Authentication Server) | (Locally Configured) }
ReAuthAction = { Terminate | Reauthenticate }
TimeToNextReauth = 1453 Seconds
PortStatus = AUTHORIZED
MaxReq = 2
HostMode = Single (AUTH-FAIL-VLAN)
Port Control = Auto
QuietPeriod = 60 Seconds
Re-authentication = Disabled
ReAuthPeriod = 3600 Seconds
ServerTimeout = 30 Seconds
SuppTimeout = 30 Seconds
TxPeriod = 30 Seconds
Guest-Vlan = 0
This is an example of output from the show dot1x statistics interface fastethernet0/3 command.
Table 2-16 describes the fields in the display.
Switch# show dot1x statistics interface fastethernet0/3
PortStatistics Parameters for Dot1x
--------------------------------------------
TxReqId = 15 TxReq = 0 TxTotal = 15
RxStart = 4 RxLogoff = 0 RxRespId = 1 RxResp = 1
RxInvalid = 0 RxLenErr = 0 RxTotal= 6
RxVersion = 1 LastRxSrcMac 00d0.b71b.35de
Table 2-16 show dot1x statistics Field Descriptions
Field Description
TxReqId Number of Extensible Authentication Protocol (EAP)-request/identity frames
that have been sent.
TxReq Number of EAP-request frames (other than request/identity frames) that have
been sent.
TxTotal Number of Extensible Authentication Protocol over LAN (EAPOL) frames of
any type that have been sent.
RxStart Number of valid EAPOL-start frames that have been received.
RxLogoff Number of EAPOL-logoff frames that have been received.
RxRespId Number of EAP-response/identity frames that have been received.
RxResp Number of valid EAP-response frames (other than response/identity frames)
that have been received.
RxInvalid Number of EAPOL frames that have been received and have an unrecognized
frame type.
RxLenErr Number of EAPOL frames that have been received in which the packet body
length field is invalid.
RxTotal Number of valid EAPOL frames of any type that have been received.
RxVersion Received packets in the IEEE 802.1x Version 1 format.
LastRxSrcMac Source MAC address carried in the most recently received EAPOL frame.

Cisco Catalyst 2950 Specifications

General

Forwarding Bandwidth	8.8 Gbps
Switching Capacity	13.6 Gbps
Forwarding Rate	6.6 Mpps
Weight	3.6 kg
RAM	16 MB
Flash Memory	8 MB
Operating Humidity	10% to 85% non-condensing
Uplink Ports	2 x 10/100/1000Base-T
Dimensions	4.4 cm x 44.5 cm x 24.2 cm
Remote Management Protocol	SNMP, Telnet, HTTP
Features	Quality of Service (QoS), VLAN support
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p
Status Indicators	system
Operating Temperature	0 to 45°C
Ports	24 x 10/100 Ethernet ports
MAC Address Table Size	8, 192 entries
Power Supply	Internal 100-240V AC, 50-60Hz
