Cisco Catalyst 2950 Command Reference

2-482
Catalyst 2950 and Catalyst 2955 Switch Command Reference
0L-10102-01
Chapter 2 Catalyst 2950 and 2955 Cisco IOS Commands
spanning-tree vlan
Command Modes Global configuration
Command History
Usage Guidelines Disabling the STP causes the VLAN to stop participating in the spanning-tree topology. Interfaces that
are administratively down remain down. Received BPDUs are forwarded like other multicast frames.
The switch does not detect and prevent loops in a VLAN if STP is disabled for that VLAN.
You can disable the STP on a VLAN that is not currently active and verify the change by using the show
running-config or the show spanning-tree vlan vlan-id privileged EXEC command. The setting takes
effect when the VLAN is activated.
When disabling or re-enabling the STP, you can specify a range of VLANs that you want to disable or
enable.
When the STP is disabled and then enabled, all assigned VLANs continue to be its members. However,
all spanning-tree bridge parameters are returned to their previous settings (the last setting before the
VLAN was disabled).
You can enable spanning-tree options on a VLAN that has no interfaces assigned to it. The setting takes
effect when you assign interfaces to it.
When setting the max-age seconds, if a switch does not receive BPDUs from the root switch within the
specified interval, it recomputes the spanning-tree topology. The max-age setting must be greater than
the hello-time setting.
The spanning-tree vlan vlan-id root command should be used only on backbone switches.
When you enter the spanning-tree vlan vlan-id root command, the software checks the switch priority
of the current root switch for each VLAN. Because of the extended system ID support, the switch sets
the switch priority for the specified VLAN to 24576 if this value will cause this switch to become the
root for the specified VLAN. If any root switch for the specified VLAN has a switch priority lower than
24576, the switch sets its own priority for the specified VLAN to 4096 less than the lowest switch
priority. (4096 is the value of the least-significant bit of a 4-bit switch priority value.)
When you enter the spanning-tree vlan vlan-id root primary command, the switch recalculates the
forward-time, hello-time, max-age, and priority settings. If you previously configured these
parameters, the switch overrides and recalculates them.
When you enter the spanning-tree vlan vlan-id root secondary command, because of support for the
extended system ID, the software changes the switch priority from the default value (32768) to 28672.
If the root switch should fail, this switch becomes the next root switch (if the other switches in the
network use the default switch priority of 32768, and therefore, are unlikely to become the root switch).
Release Modification
12.0(5.2)WC(1) This command was introduced.
12.1(9)EA1 The priority priority range changed from 1 to 65535 to 1 to 61440 (in
increments of 4096).

Cisco Catalyst 2950 Specifications

General

Forwarding Bandwidth	8.8 Gbps
Switching Capacity	13.6 Gbps
Forwarding Rate	6.6 Mpps
Weight	3.6 kg
RAM	16 MB
Flash Memory	8 MB
Operating Humidity	10% to 85% non-condensing
Uplink Ports	2 x 10/100/1000Base-T
Dimensions	4.4 cm x 44.5 cm x 24.2 cm
Remote Management Protocol	SNMP, Telnet, HTTP
Features	Quality of Service (QoS), VLAN support
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p
Status Indicators	system
Operating Temperature	0 to 45°C
Ports	24 x 10/100 Ethernet ports
MAC Address Table Size	8, 192 entries
Power Supply	Internal 100-240V AC, 50-60Hz
