14
System Management Menu
To access the user menu, enter the code and press the 'prog' key, whether the system is activated or
deactivated.
The user menu consists of a certain number of options, divided into sub-menus.
IMPORTANT: When the product leaves the factory, only User 1 is available and enabled with the code 111111.
N.B.: user menu presentation is dynamic. Menu options are only displayed if the user logged in to the
control panel possesses the required authorisation. The menu tree is shown in full below.
Modifying a numerical value
To modify a numerical value, type in the desired value, following the format shown on the display, omitting
non-numerical characters, but filling in all the numerical characters of the proposed format.
e.g. date DD-MM-YY must be entered as DDMMYY; 2 September 2015 will become 020915, without
dashes but with a zero at the beginning to fill the tens digit for the days.
e.g. Setpoint 1.14 is entered as 114, without the decimal point.
Modifying an alphanumerical value
Once you have selected the string you wish to change (for example, the description of a zone) the first
character available for editing will start to flash. At this point characters can be entered or replaced using
the same technique as used in mobile telephones with a pushbutton keypad. Press the same key several
times to change the suggested character in accordance with a set sequence. The table below shows the
sequence of characters available for each key.
Press the C key when the first character is flashing to exit the string without saving any changes.
To move around within the string, use the right and left navigation keys.
Pressing the C key while inside the string deletes the character to the left of the flashing character.
The new character, when necessary, will be entered to the left of the flashing character.
Press Confirm to save the changes.
The table below lists the character sequence for each key.
Number key Corresponding character sequence
1 . , : ; _ - # * ' @ / 1
2 A B C a b c 2
3 D E F d e f 3
4 G H I g h i 4
5 J K L j k l 5
6 M N O m n o 6
7 P Q R S p q r s 7
8 T U V t u v 8
9 W X Y Z w x y z 9
0 (space) 0
Navigation mode
Use the keys to move about in the menu and the key to pass to the next level or to
confirm the entry of a new data item.
Press C to return to the previous menu.
