Buzzer
The buzzer integrated into the reader beeps to signal successful reading of an RFID key, and confirms the
procedures completed using the key.
(*) The purpose of forcing is to overcome a 'not ready' condition in one or more of the zones associated
with the areas covered by the reader, and/or an fault which can be overridden due to the choices made
at the time of control unit configuration.
MEANING OF THE LEDs WITH THE READER IN STANDBY
(no cycle in progress)
LED Status Function
Red
On Scenario associated with the Red LED active
Slow
flash
System not activated and alarm, tampering or fault event memory present
Fast flash System activated and alarm, tampering or fault event memory present
Blue
On Scenario associated with the Blue LED active
Slow
flash
System activated with unknown scenario (not saved)
Yellow
On Scenario associated with the Yellow LED active
Fast flash Fault present
Green
On Scenario associated with the Green LED active
Fast flash System not ready for enabling or there are (non-excluded) open zones
MEANING OF LEDs DURING PRESENTATION OF THE KEY
LED Status Function
Red
O Request for deactivation of all areas covered by the reader.
On Request for activation of the activation profile associated with the RED LED
Fast flash The reader is forcing the activation profile associated with the RED LED (*)
Blue
O Request for deactivation of all areas covered by the reader.
On Request for activation of the activation profile associated with the BLUE LED
Fast flash The reader is forcing the activation profile associated with the BLUE LED (*)
Yellow
O Request for deactivation of all areas covered by the reader.
On Request for activation of the activation profile associated with the YELLOW LED
Fast flash The reader is forcing the activation profile associated with the YELLOW LED (*)
Green
O Request for deactivation of all areas covered by the reader.
On Request for activation of the activation profile associated with the GREEN LED
Fast flash The reader is forcing the activation profile associated with the GREEN LED (*)
MEANING OF THE LEDS WHEN THE CYCLE IS IN PROGRESS
LED Status Function
Red
On Request execution of action associated with LED
Slow
flash
Action associated with LED requires forcing to be executed
Blue
On Request execution of action associated with LED
Slow
flash
Action associated with LED requires forcing to be executed
Yellow
On Request execution of action associated with LED
Slow
flash
Action associated with LED requires forcing to be executed
Green
On Request execution of action associated with LED
Slow
flash
Action associated with LED requires forcing to be executed
