Upgrading RAM Memory 11-3
Writer: Carey Gregg Saved by: Rebecca Wiggins Saved date: 02/04/98 4:43 PM
Part Number: 314932-001 File name: Ch11.doc
Removing a Memory Expansion Slot Cover
On a model that ships with a preinstalled memory expansion
board, the memory expansion slot cover is secured with a tamper-
resistant memory expansion slot cover security screw. Use the
Torx T-10 screwdriver included with the computer to remove and
reinsert this screw.
On a model that ships with an empty memory expansion
compartment, the memory expansion slot cover is attached with a
standard Torx T-8 screw. Use a standard Torx T-8 screwdriver to
remove and reinsert this screw.
Two memory expansion slot cover security screws are included
with the computer. The factory-installed Torx T-8 screw can be
replaced with a security screw.
To remove the memory expansion slot cover:
CAUTION:
Electrostatic discharge (ESD) can damage electronic
components. Before beginning this procedure, ensure that you are
properly grounded.
1
Save your work, exit all applications, and shut down the
computer.
NOTE:
If you are unsure whether the computer is off or in
Hibernation, turn the computer on, then shut it down.
!
WARNING:
Failure to unplug the power cord and remove the
battery pack before installing a memory expansion board can
damage the equipment and expose you to the risk of electrical
shock.
2
Disconnect all external devices connected to the computer.
3
Disconnect the power cord.
4
Remove the battery pack(s) from the computer.
5
Turn the computer upside down on a flat surface with the rear
panel facing you.
