Removing a Memory Expansion Board
1
Lift and hold back the memory insulator
1
.
2
Pull away the plastic retention clips on each side of the
memory expansion board to release it
2
. The memory
expansion board tilts toward you.
3
Lift the edge of the memory expansion board and slide it
gently out of the memory expansion slot at a 45-degree
angle
3
.
4
Place the removed memory expansion board in an
electrostatic-safe container.
