Inserting a Hard Drive into the MultiBay
CAUTION:
To prevent damage to the computer and hard drive and
loss of information, turn off the computer before inserting a hard
drive into the MultiBay. Do not insert the hard drive while the
computer is turned on, in Suspend, or in Hibernation.
Electrostatic discharge can damage electronic components. Before
touching the hard drive, ensure that you are discharged of static
electricity by touching a grounded metal object.
1 Turn off the computer.
2 Insert the hard drive, with the label facing up, into the Hard
Drive MultiBay Adapter.
3 Position the hard drive carrier against the left side of the
MultiBay.
4 Slide the Hard Drive MultiBay Adapter into the MultiBay
until it locks into place.
