DMD1050TS Satellite Modem Board
Revision 1
Web Browser 7–45 MN-DMD1050TS
Interface | RX Setup Page
BUFFER CLOCK SOURCES Section
Source 1 of 1
•
SCTE (External)
• SCT (Internal)
• RX SAT
• EXT BNC
•
EXT IDI
Use to assign priorities to the clock sources. The highest
priority is 1, and 5 is the last resort.
Source 2
•
SCTE (External)
• SCT (Internal)
• RX SAT
• EXT BNC
•
EXT IDI
Use to assign priorities to the clock sources. The highest
priority is 1, and 5 is the last resort.
Source 3
•
SCTE (External)
• SCT (Internal)
• RX SAT
• EXT BNC
•
EXT IDI
Use to assign priorities to the clock sources. The highest
priority is 1, and 5 is the last resort.
Source 4
•
SCTE (External)
• SCT (Internal)
• RX SAT
• EXT BNC
•
EXT IDI
Use to assign priorities to the clock sources. The highest
priority is 1, and 5 is the last resort.
Source 5
•
SCTE (External)
• SCT (Internal)
• RX SAT
• EXT BNC
•
EXT IDI
Use to assign priorities to the clock sources. The highest
priority is 1, and 5 is the last resort.
ASYNC Section
Async Mode
•
ES-ES
• ESC ENHANCED
Read only; ES-ES is the normal IBS Async Channel. ESC
ENHANCED is applicable for Closed Net. It uses the
Overhead Signaling bytes in the IBS Overhead to pass
asynchronous data.
ES Interface
• RS-232
• RS-485
Read only; shows the interface type.
ES Baud Rate • 150 - 19200 Read only; shows the baud rate in Enhanced Async Mode.
ES Bits/Char
•
7
• 8
Read only: shows 7- or 8-bit data.
INSERT MAP Section – Not available on the DMD1050TS
Insert Mode
N/A
N/A
T1 / E1 Frame Scr
N/A
N/A
Sat Channel
N/A
N/A
Terr TSlot
N/A
N/A
