94 • DM NAX® Product Manual — Doc. 9045M
Balanced/Unbalanced Audio Output
Refer to the following table and illustration for analog audio output pin assignments and connection
information.
Signal Name Balanced Audio Output Unbalanced Audio Output
+ L+ L+
- L− L Shield
G Shield/ground G, L Shield, and R Shield
+ R+ R+
- R- R Shield
Apple® AirPlay® Setup
The DM-NAX-4ZSP supports AirPlay 2 and requires iOS11.4 or later.
AirPlay can be enabled on any of the built-in media players on the DM-NAX-4ZSP.
To stream media from an iOS device to an output zone in your distributed audio system:
1. Ensure that the iOS device and DM-NAX-4ZSP are on the same network.
2. On the DM-NAX-4ZSP, enable AirPlay for the built-in media player you would like to stream to,
either using the web UI or programming.
NOTE: If the control/media and Audio-over-IP network traffic is isolated between two
network ports on the DM-NAX-4ZSP, AirPlay will use the port specified for the Control/Media
traffic.
3. On your iOS device:
a. Enable AirPlay
b. From the list of available AirPlay destinations, select the DM-NAX-4ZSP zone you would like
to stream to.
The media player will play back audio to the selected zone(s).
Once AirPlay streaming begins, you will be able to control the volume of the streaming DM-NAX-4ZSP
output zones directly from your iOS device.
