32 • DM NAX® Product Manual — Doc. 9045M
Specifications
Refer to the following sections for more information on the specifications for various DMNAX devices.
l
DM-NAX-2XLRI-1G
l
DM-NAX-8ZSA
l
DM-NAX-4ZSA-50
l
DM-NAX-4ZSP
l
DM-NAX-16AIN
l
DM-NAX-AMP-X300
l
DM-NAX-AUD-IO
l
DM-NAX-AUD-USB
l
DM-NAX-BTIO-1G
DM-NAX-2XLRI-1G Specifications
Product specifications for the DM-NAX-2XLRI-1G are provided below.
Specifications
Audio
Input Signal Types Balanced/unbalanced analog line/mic-level;
DMNAX/AES67 audio-over-IP
Output Signal Types Balanced/unbalanced analog line-level;
DMNAX/AES67 audio-over-IP
Source Compensation ±10.0dB per input
Input Monitoring Source Signal Detect
Frequency Response (at
line-level output)
From mic-level input: 20Hz to 20kHz ±1.0dB;
From line-level input: 20Hz to 20kHz +0.1/-1.0dB
THD+N (at line-level
output)
From mic-level input: 0.3% @ 1kHz, max output
From line-level input: 0.005% @ 1kHz, max output
S/N Ratio (at line-level
output)
From analog input: 105dB, 20Hz to 20kHz, A-weighted;
From digital input: 111dB, 20Hz to 20kHz, A-weighted
Balance Control Left/right adjustable
EQ Filter Types EQ, High Pass, Low Pass, Treble Shelf, Bass Shelf, Notch
EQ Center Frequency 10Hz to 20kHz per band
EQ Gain +20/-40dB per band
EQ Bandwidth 0.1 to 4.0octaves per band
