DM-NAX-AUD-IO Installation
Refer to the following sections to install the DM-NAX-AUD-IO.
l
In the Box on page 117
l
Mount the Device on page 117
l
Connect the Device on page 121
l
Reset the Device on page 123
In the Box
Qty. Description
1 DM-NAX-AUD-IO
Additional Items
1 Single gang electrical box adapter bracket, galvanized metal (2059673)
2 Surface mount bracket, aluminum (2059674)
2 Connector, 5-pin (2003577)
2 Screws, M3 x 6 mm, Flat Head, Phillips (2062526)
4 Screws, M3 x 0.5 x 6 mm, Pan Head, Phillips (2058870)
1 Polycarbonate front panel label (4536923)
Mount the Device
The DM-NAX-AUD-IO can be mounted under a table, into a 1-gang electrical box, or onto a rack rail.
Mounting under a Table
To mount the device under a table:
1. Using a Phillips screwdriver, remove the four flat head screws from the left and right panels of the
device.
2. Align the two included right angle surface mount brackets with the left and right panels of the
device. For mounting under a table, keep the flanged surface of the brackets flush with the top
panel of the device. For mounting to a surface, keep the flanged surface of the brackets flush with
the bottom panel of the device.
To Next Page
