Product Manual — Doc. 9045M DM NAX® • 510
2. To set the maximum volume of the zone, do one of the following:
l
Move the Maximum slider to the right to increase or to the left to decrease the maximum
volume.
l
Click the % arrows to increase or decrease the maximum volume. Values range from 70 to
100%, adjustable in increments of 1%.
l
Manually enter a value in the Maximum field.
NOTE: When a Minimum and Maximum volume are set, the 1-100% range represented by the
Zone and Default volume controls are scaled to the range set. For example, if a Minimum of
10% and a Maximum of 80% are set for a zone, the 1-100% range of the Zone volume control
is scaled to the 10%-80% range set as the Minimum and Maximum.
3. To set the default volume of the zone, do one of the following:
l
Move the Default slider to the right to increase or to the left to decrease the default
volume.
l
Click the % arrows to increase or decrease the default volume. Values range from 0 to 50%,
adjustable in increments of 1%.
l
Manually enter a value in the Default field.
NOTE: The Default volume is applied as the Zone volume any time the zone receives a source
route and no source was previously routed to that zone.
Stereo/Mono
Select either Stereo or Mono from the Stereo/Mono radio buttons. If Stereo is selected, both output
channels can have independent audio content. If Mono is selected, both output channels receive the
same audio content.
Signal
The Signal section is a read-only field that displays the Signal and Clipping status of the zone output.
