Product Manual — Doc. 9045M DM NAX® • 504
l
Enabled: When DHCP is enabled (default setting), the IP address of the DM-NAX-AUD-IO is
automatically assigned by a DHCP server on the local area network (LAN).
l
Disabled:When DHCP is disabled, manually enter information in the following fields:
o
Primary Static DNS: Enter a primary DNS IP address.
o
Secondary Static DNS: Enter a secondary DNS IP address.
o
IP Address: Enter a unique IP address for the DM-NAX-AUD-IO.
o
Subnet Mask: Enter the subnet mask that is set on the network.
o
Default Gateway: Enter the IP address that is to be used as the network’s gateway.
To save any new network entries, click Save Changes.
Control System
1. Click the Encrypt Connection button to navigate to the Security tab to configure encryption
settings.
2. Enter the username in the Control System Username field.
3. Enter the password in the Control System Password field.
4. Enter the Room ID in the Room ID field.
5. Enter the IP IDof the DM-NAX-AUD-IO in the IP ID field.
6. Enter the IP address or hostname of the control system in the IP Address/Hostname field.
7. Click the Save Changes button to save the new entries. The Control System Save message box
appears, indicating that the control system settings were saved successfully. Click the Revert
button to revert to the previous settings without saving.
Cloud Settings
Set the Cloud Settings toggle to enabled (right) or disabled (left) to specify whether the
DM-NAX-AUD-IO can communicate with the XiOCloud® platform.
Device Modes
Use the Device Modes section to configure the Application Mode.
